2026-09-15: Claude Code Tool Surface and the Quota Failover Ladder

Technical pencil sketch of a mechanical routing exchange switchboard with glowing cyan and amber data circuits routing through a failover gate into a secure vault.

A critical alert buzzed Bert’s phone: [Sanctum CRITICAL] proxyd e2e: Claude Code tool surface left the subscription.

To Windu and the sentinel, it looked like a repeat of the September 11 regression where a stale binary stripped client tools against the host-tools policy. The reality was a chain of three distinct friction points: an expired OAuth bearer in the macOS Keychain, a file mode boundary blocking the system daemon user, and a missing fallback ladder for Claude Opus 5 during an upstream account spend limit.

1. The Keychain Bearer Expiration

Section titled “1. The Keychain Bearer Expiration”

The proxyd-sentinel runs proxy-route-e2e.py --group claude-code every six hours, issuing real turns with the full 30-tool Claude Code surface (CLAUDE_CODE_TOOLS) authenticated as the CLI.

At 18:24 EDT, the OAuth bearer stored in Keychain item Claude Code-credentials expired. Qui-Gon’s automated token refresher (sanctum-token-refresh.sh) had backed off after encountering HTTP 429 rate limits from Anthropic’s token endpoint (https://platform.claude.com/v1/oauth/token).

Bert initiated an interactive authentication grant via claude auth login, approved the browser challenge, and stored a fresh access token valid for eight hours.

2. Permission Boundary Hardening

Section titled “2. Permission Boundary Hardening”

With the token renewed in the Keychain, sanctum-token-refresh.sh synchronized the credentials to ~/.sanctum/credentials/anthropic-token. However, the refresher wrote the file with mode 600 owned by bert:sanctum.

proxyd runs as the dedicated system daemon user sanctum under /Library/LaunchDaemons/haus.sanctum.proxyd.plist. Mode 600 meant user sanctum was denied read access to the token upon daemon launch.

The refresher script was updated across all write paths to enforce mode 640 while keeping group ownership sanctum:

Terminal window
echo -n "$NEW_ACCESS" > "$TOKEN_FILE"
chmod 640 "$TOKEN_FILE"
chgrp sanctum "$TOKEN_FILE" 2>/dev/null || true

Both operator terminal sessions and background daemon workers now share read access without opening secrets to world permissions.

3. Upstream Monthly Spend Limit

Section titled “3. Upstream Monthly Spend Limit”

Even with valid credentials and readable files, native Anthropic requests failed with HTTP 429:

You've hit your org's monthly spend limit · run /usage-credits to raise it, or visit claude.ai/admin-settings/usage · your session limit resets 10:40pm (America/Toronto)

The error proved that the upstream Claude Max organization account had reached its monthly spend limit, scheduled to reset at 10:40 PM EDT.

Inside sanctum-proxy, is_backend_quota_exhausted() recognized the spend limit signature and marked provider:anthropic exhausted for the remainder of the request. This triggered the proxy’s failover machinery:

  • Claude Fable 5.1: Followed its explicit ladder (kimi-k3 -> glm-53 -> deepseek-v3), diverting to Moonshot Kimi K3 on OpenRouter at $0.006/turn.
  • Claude Opus 5: Lacked an explicit entry under fallbacks: in config.yaml. Without a ladder, fallback_chain() dropped straight to CLAUDE_OFFLINE_FALLBACK (council-mlx), which was under heavy load from a concurrent 49k-token inference stream and timed out.

4. Closing the Opus Fallback Ladder

Section titled “4. Closing the Opus Fallback Ladder”

To prevent unhandled failover stalls when Anthropic’s subscription or bridge hits quota, claude-opus-5 was assigned the canonical Opus degrade ladder in sanctum-proxy/config.yaml:

  claude-opus-5:
  - claude-best-pro
  - claude-cli-offline
  - gemini-best-pro
  - grok-best
  - glm-53
  - qwen36-plus
  - deepseek-v3
  - council-local-think
  - council-mlx

proxyd hot-reloaded the configuration instantly. Re-probing claude-opus-5 with tools confirmed the degrade sequence:

  1. Attempted native claude-opus-5 (429 upstream spend limit).
  2. Attempted :3456 subscription bridge (claude-best-pro, 429 upstream spend limit).
  3. Landed on gemini-best-pro (:6543) at $0.00000 in 29.1s with status 200.

5. Verification

Section titled “5. Verification”
  • Token Validity: sanctum-token-refresh.sh confirmed Token valid (471 min remaining) with mode 640.
  • Sentinel Health: proxyd-sentinel.sh ran clean with active=none.
  • E2E Probe: cc · opus-5 + CC tools verified PASS with zero metered spend.

When quota expires, the switchboard does not drop the line: it routes through the next vault door until the clock strikes 10:40 PM.
