The best interface in Sanctum is the one Bert uses without thinking. He opens Signal, texts a thread named “Yoda,” and gets a reply in the Jedi Master’s cadence — same UX as texting a friend. Behind that thread sits a 35B-parameter Qwen running locally on the Mac Mini via sanctum-mlx, an openclaw agent with the persona, and seven hops between the two.
When the chat is healthy, none of that is visible. When it isn’t, the silence is deafening — and we learned the hard way that silence has many causes.
The Holocron Bridge is the system that keeps the chat alive: the transport, the dispatcher, the agent, the watchdog, and a single CLI that gives you the truth in two seconds.
Signal Server │ ▼ signal-cli daemon (Mac) TCP localhost:7583 │ socat bridge 10.10.10.1:7583 │ ▼ ┌───────────────────────────┐ │ yoda-chat (this pkg) │ │ │ │ ┌──────────┐ │ │ │ proxy │ HTTP-JSON- │ │ │ :5150 │ RPC for │ │ │ │ openclaw │ │ ├──────────┤ │ │ │ consumer │ inbound │ │ │ │ dispatcher │ │ └──────────┘ │ └───────────────────────────┘ │ ▼ openclaw agent CLI subprocess `openclaw agent --agent main --json` │ ▼ council-local provider via TLS bridge http://10.10.10.1:1339 → :1337 │ ▼ sanctum-mlx (Mac, 64 GiB)| # | Hop | Host | Port | Purpose |
|---|---|---|---|---|
| 1 | Signal Server | cloud | — | The thing that delivers messages between phones |
| 2 | signal-cli daemon | Mac | TCP :7583, HTTP :8080 | Long-poll Signal Server, expose JSON-RPC |
| 3 | socat bridge | Mac → VM | 10.10.10.1:7583 | NAT-friendly TCP forward to VM |
| 4 | yoda-chat-proxy | VM | :5150 | HTTP-JSON-RPC ⇄ TCP-JSON-RPC and SSE for openclaw |
| 5 | openclaw-gateway Signal channel | VM | :1977 | Subscribes to proxy SSE /api/v1/events, runs agent |
| 6 | sanctum-mlx / proxyd | Mac | TLS :4040 → cathedral | Local (or tiered) inference for the reply |
One transport, one connection
Every component shares the same Python SignalTransport — a single persistent TCP-JSON-RPC client to signal-cli. Reconnect with bounded exponential backoff, fail-fast on disconnect (so callers don’t hang), and one writer per process. No race between subscribers; no zombie sockets.
No silent failures
Every hop has a structured log. Every envelope is classified — data / receipt / typing / sync / other. Receipts and typing indicators are visibly logged so silence in the log reflects an actual silence, not a misparse. The Connection closed unexpectedly line that used to look terrifying is now a footnote — it’s signal-cli’s normal long-poll cycle.
Self-heal on two sides of the airgap
VM: yoda-chat-doctor.timer every 10 min (workspaces, poisoned sessions, yoda-chat-proxy restart). Mac: launchd KeepAlive for signal-cli/bridge, plus com.sanctum.signal-link-sentinel readiness every ~5 min and an R2D2 recipe heal-yoda-signal-link every 10 min — including channel-disabled, SSE-contract-broken, and gateway-down (the 2026-07-16 class). Tracked goldens under ~/.sanctum/yoda-chat/.
$ yoda-chat statusThe Holocron Bridge — OK
✓ signal-cli TCP 10.10.10.1:7583 27ms v0.14.4.1 ✓ signal-proxy :5150 12ms healthy ✓ mlx bridge http://10.10.10.1:1339 24ms 1 model(s) ✓ yoda-chat consumer log 0ms active (7s ago) ✓ Yoda session 4ms session d73c1c95, 4 turns ✓ Workspace bootstrap state 0ms all workspaces stamped complete
Account: +15555550100 Operator: +15555550100 Session: d73c1c95 Turns: 4 Last in: Where the work continues, friend? Last out: Strong with the Force, you are.
Calm, the Force is.yoda-chat doctor walks the same checks but applies remediation:
setupCompletedAt? Stamp it.systemctl --user restart yoda-chat-proxy (and bounce openclaw-gateway so it re-subscribes to SSE).yoda-chat e2e is the no-mercy regression test. It exercises every hop in order — signal-cli TCP version probe, proxy /api/v1/check, mlx /v1/models, an agent CLI round-trip that demands the word PONG, then (unless --no-deliver) a real proxy → operator send and an agent --deliver round-trip — and prints a green checkmark per stage with a duration. If it’s all green, the chat works. If not, the failing stage names the problem.
Bundled openclaw extensions stage their npm deps on every load.
The VM is offline. Every load hung forever on npm install @mariozechner/pi-ai. Disabling each extension didn’t help (the staging path bypasses the deny list); the fix was to pre-populate sentinel package.json files in each extension’s node_modules/<dep>/ so the staging code believed the deps were already there. The runtime has since moved to a pnpm-managed store and the extensions/ dir is empty, so the sentinels are gone — but the lesson (stage, don’t fetch, on an air-gapped box) is the one we’d relearn the hard way.
signal-cli-rest-api Docker containers are retired.
Native signal-cli on TCP :7583 is the live transport. Don’t put a REST shim in front. The previous signal-proxy.js translated JSON-RPC ⇄ REST against dead Docker IPs (10.0.0.1:18081/18082). The new yoda-chat proxy forwards JSON-RPC verbatim to TCP — no translation, no impedance mismatch.
Session poisoning is the silent killer.
If the agent ever falls into a “Bootstrap is still pending” reply (because some workspace hasn’t been stamped), every subsequent ambiguous prompt continues that pattern. The model is doing the right thing — continuing the conversation. But the conversation is poisoned. The session JSONL has to be archived. yoda_chat.session.archive_poisoned_session_for() does this automatically; the doctor runs it on every tick.
setupCompletedAt must be set in every workspace.
Both the per-agent sandbox (sandboxes/agent-<id>-*/.openclaw/workspace-state.json) AND the runtime workspace (workspace/.openclaw/workspace-state.json), and the per-Jedi siblings: workspace-windu, workspace-cilghal, workspace-mundi, workspace-quigon. stamp_workspaces_complete() does all of them.
The 100ms WebSocket reconnect log is normal.
signal-cli polls Signal Server in short bursts; the Connection closed unexpectedly, reconnecting in 100 ms is the long-poll cycle completing, not a fault. Don’t restart the daemon on this signal.
pkill -f openclaw over SSH closes your own session.
The shell that’s running pkill matches the pattern. Use specific PIDs, pkill -x (exact match), or pkill -f <very-specific>.
Outbound green ≠ inbound healthy (2026-07-16).
Agent --deliver and proxy send can succeed while Bert→Yoda is mute. Causes that stayed green under naive health: channels.signal.enabled=false on the VM gateway config; yoda-chat SSE wrapping envelopes under method/params so OpenClaw never saw payload.envelope. Always check inbound readiness:
python3 ~/.sanctum/sentinels/signal-link-sentinel.py --check and
ssh yoda 'python3 ~/.openclaw/yoda-chat/scripts/inbound-readiness.py'.
yoda-chat status from any host. Either Mac or VM. The first failing row names the broken layer.
If it’s all green but no reply lands: check the session row. If turns is high and Last out: starts with “Bootstrap is still pending”, the session is poisoned. yoda-chat doctor archives it.
If signal-cli TCP is red: the Mac daemon is down or the bridge is broken. On Mac: launchctl list | grep com.sanctum.signal should show com.sanctum.signal-cli and com.sanctum.signal-tcp-bridge. Kickstart with launchctl kickstart -k gui/$(id -u)/com.sanctum.signal-cli.
If signal-proxy is red but signal-cli TCP is green: the VM proxy is down. ssh [email protected] systemctl --user restart yoda-chat-proxy. The doctor timer will catch this within 10 min anyway.
If mlx bridge is red: sanctum-mlx is down or the TLS-termination bridge isn’t running. The bridge is com.sanctum.yoda-plain-bridge (it terminates TLS at :1339 onto sanctum-mlx at :1337); launchd KeepAlive usually respawns it, but if it’s wedged, manual: launchctl kickstart -k gui/$(id -u)/com.sanctum.yoda-plain-bridge.
If everything is green and you still feel something is off: run yoda-chat e2e. It will send two test messages to the operator’s Signal — proof of outbound life. Then run the inbound probe: ssh yoda 'python3 ~/.openclaw/yoda-chat/scripts/inbound-readiness.py' — all five fields must be true. If sse_contract_ok is false, re-apply goldens: ~/.sanctum/yoda-chat/apply-inbound-goldens.sh. Full story: 2026-07-16 silent inbound.
