Diagnosing Your Network

Your network is almost certainly fine. The tools you used to check it probably are not. A speed test lies, an ISP app names the wrong suspect, and a topology you didn’t choose quietly costs you nothing — or quietly breaks port-forwarding for the one service you actually wanted to reach. Sanctum ships three net commands that diagnose all of this honestly. They live under one verb and you run them in order: check, then optimize if you must, then speedtest when the number looks wrong.

Everything here is in the CLI reference. This page is the newcomer’s walkthrough.

Is my network double-NATed?

Start read-only. sanctum net check never changes anything — it works out whether your traffic passes through one router or two, names your ISP, and shows the reasoning.

sanctum net check

It prints the NAT topology (single, double, or unknown), the ISP and gateway it found, and one line of why. Double-NAT means your own router sits behind the ISP’s hub, both doing address translation. It usually does no harm to speed — but it complicates port-forwarding, VPN inbound, and anything that needs a stable public address. If check says you’re already single-NAT, you are done; close the terminal.

Note

Read the reasoning line, not just the verdict. A double-NAT call is only as trustworthy as the evidence it cites — and the same discipline (read the whole alert, not the headline) is what untangled the worst Bell cutover we ever logged.

Optimize — single-NAT, with the honest caveats

If check found double-NAT and you want your own router holding the public IP, sanctum net optimize is the guided path. It is opt-in and reversible: it snapshots a rollback baseline before anything changes, warns you the cutover briefly drops your internet, and follows a playbook tailored to your ISP.

1. Dry-read the plan. sanctum net optimize --plan-only prints the ISP-specific steps and stops — no snapshot, no prompt, no changes. Read it before you commit.

2. Be at the box. This drops the link mid-cutover. Run it physically next to the router, not over SSH from a café. The wizard asks; --yes skips the question if you already know.

3. Run the steps, then let it verify. It captures a rollback snapshot, you do the steps, and it probes the result — reporting VERIFIED, or APIPA_ROLLBACK (the box fell back to a self-assigned 169.254.x.x address; the change failed and it prints the rollback commands), or an inconclusive note.

The Bell traps are real — the wizard surfaces them

Bell’s Advanced DMZ hands out a /1 WAN netmask (128.0.0.0) that swallows an entire 10.x LAN, so the wizard checks your subnet first and steers 10.x users to PPPoE-passthrough instead. It also sets the WAN MTU to 1492 as a named step — Bell’s fibre carries 1492, and a 1500 MTU with no MSS clamp black-holes HTTPS while ping still passes. Neither is a Sanctum quirk; both are baked in because they cost real hours. The full forensic: The Slash-One That Ate the LAN.

Speedtest — why your 8-gig line “tests slow”

The most common network complaint is a multi-gig line that benchmarks at a fraction of the plan. The line is usually fine. The test is the bottleneck. sanctum net speedtest is the honest doctor: it runs a multi-stream test, reads the link speed of every hop it can see, and names the real ceiling.

sanctum net speedtest
sanctum net speedtest --streams 16   # more parallel streams on a very fast line
sanctum net speedtest --no-test      # ceiling audit only, no live download
sanctum net speedtest --json         # machine-readable report

It walks your NIC, whether you’re on Wi-Fi or wired, and the Firewalla’s WAN/LAN ports when reachable — then runs a bounded parallel download and interprets the gap. The artifacts it exposes:

• Single-stream cap. One TCP stream stalls near 1-2 Gbps no matter how fast the line is. When parallel streams fly, the single number was the lie — trust the multi-stream figure.
• Wi-Fi. Wi-Fi caps you around 1-2 Gbps regardless of the fibre behind it. Go wired and re-test, or you are measuring the air.
• Port artifacts. A 1G switch or a 2.5G NIC anywhere in the chain is your ceiling; no line upgrade moves it. The doctor names the slow hop.
• NAT, again. Single- vs double-NAT changes throughput by zero. Do not chase your topology to go faster — that ghost has wasted more evenings than any real bug.

Tip

If too few streams complete, speedtest calls the number a FLOOR, not the truth — your line is at least that fast. Raise --streams, re-run, or install the Ookla speedtest CLI for a cleaner figure. The story of an 8-gig line that benchmarked at 1.86: The Speed Test That Cried Slow.

Deeper reading

The two field notes below are the postmortems these commands were built from — they are where the doctrine came from, written the night each lesson was earned.

• The Slash-One That Ate the LAN — the /1 netmask and the 1492 MTU black-hole, two bugs in one trenchcoat.
• The Speed Test That Cried Slow — three lies a speed test tells, and the test that tells the truth.
