Le Sanctum

Firewalla Pairing

Firewalla pairing — a brass router on an oak desk wired to a metal vault with three combination dials; a teal handshake at the contact point because handshakes are the only honest way to exchange a secret.

It’s 21:31. Curfew dropped eleven minutes ago, your dashboard swears the kid’s iPad is BLOCKED in cheerful green — and yet there’s lowkey TikTok audio leaking under the bedroom door. The dashboard isn’t lying, exactly. It just asked the wrong oracle.

Here’s the thing: the Firewalla MSP HTTP API is the loud, well-documented front door, and it straight up lies about which devices it actually knows. So Sanctum doesn’t use it. We drive MAC-level enforcement through the node-firewalla SDK instead — the bridge running on your Mac talks to your Firewalla over the SDK’s encrypted P2P protocol. The side door. The one that tells the truth, no cap.

You need to do three things: mint a token, drop in the FWGroup credentials, and restart the bridge. Let’s go.

Pair

Section titled “Pair”

  1. Generate a strong bridge token.

    Terminal window
    TOKEN=$(openssl rand -hex 24)
    printf '%s' "$TOKEN" > ~/.sanctum/secrets/firewalla-bridge-token
    chmod 600 ~/.sanctum/secrets/firewalla-bridge-token

    The bridge is run by the LaunchAgent watchdog com.sanctum.firewalla-bridge-watchdog, and the filesystem secret is the primary store: the wrapper at ~/.sanctum/scripts/firewalla-bridge.sh reads this file first and only falls back to the Keychain item (-a sanctum -s firewalla-bridge-token) for legacy user-session setups.

  2. Locate your Firewalla’s FWGroup credentials.

    These are the SDK’s actual authentication artifacts — the keys that let the bridge speak to your Firewalla device. They live at ~/.openclaw/firewalla/keys/ and the bridge expects four files:

    Terminal window
    ls ~/.openclaw/firewalla/keys/
    # Expected: etp.private.pem  etp.public.pem  group.json  ssh_firewalla

    If you have already paired Firewalla using the Firewalla CLI or the official mobile app, copy that pairing’s keys/ directory into place. If you have never paired, follow Firewalla’s first-pair instructions on their site, then copy the resulting keys/ directory here.

  3. Let the bridge find your Firewalla.

    You don’t hand-configure an IP. The bridge discovers the box on its own — env override first (FIREWALLA_LAN_IP), then the last-known-good in ~/.openclaw/firewalla/keys/topology.json, then mDNS (firewalla.home, firewalla.local, and the per-model names). It deliberately refuses to fall back to a hardcoded address: a stale literal would SSH whatever happens to sit at that IP on a re-numbered LAN.

    If you genuinely need to pin the box — a quiet mDNS network, a VLAN that swallows broadcasts — set FIREWALLA_LAN_IP in the wrapper’s environment. That’s the one escape hatch, and it’s an env var, not a YAML field.

  4. Restart the bridge.

    Terminal window
    launchctl kickstart -k gui/$(id -u)/com.sanctum.firewalla-bridge-watchdog

    The live service is the gui-domain watchdog com.sanctum.firewalla-bridge-watchdog, which runs as your login user — no sudo, and the gui/$(id -u)/ domain is the one that finds it.

  5. Verify.

    Terminal window
    curl -s http://127.0.0.1:1984/health | jq '{sdkReady, firewalla: .firewalla.ip, mode: .box.mode}'
    TOKEN=$(cat ~/.sanctum/secrets/firewalla-bridge-token)
    curl -s -H "Authorization: Bearer $TOKEN" http://127.0.0.1:1984/hosts | jq '.hosts | length'

    /health returns 200 to anyone and tells you whether the SDK linked up. /hosts is the real test: it demands the bearer token and returns the actual device roster from your Firewalla. A non-zero host count means both halves are honest — the token is accepted and the SDK is talking. A bridge that’s up while the SDK is mute is the worst-case silent failure — green light, zero enforcement — and /hosts is the one call that catches it.

Troubleshooting

Section titled “Troubleshooting”

  • /hosts returns 401 — the bridge didn’t get your token. Check the filesystem store first: cat ~/.sanctum/secrets/firewalla-bridge-token should print it. If the file is empty or missing, re-run the create step. If you’re on a legacy Keychain setup, confirm the item is under the right account: security find-generic-password -a sanctum -s firewalla-bridge-token -w. Note the account is sanctum, not your login user — the wrapper reads -a sanctum, so a token filed under $(whoami) is invisible to it.

  • Bridge log shows [error] GET /hosts: ECONNRESET — the FWGroup credentials in ~/.openclaw/firewalla/keys/ are stale, or two bridge processes are racing for the same Firewalla. Confirm only one is running: pgrep -fl firewalla-bridge.js. If two, launchctl kickstart -k gui/$(id -u)/com.sanctum.firewalla-bridge-watchdog and let launchd settle the contest.

  • You see periodic check (60s without successful op) in the log — this is the bridge’s rediscovery checker, not a host-query failure signal. It fires when 60s pass with no successful contact and quietly re-runs mDNS to recover a re-IP’d box. Discovery runs separately from your actual /hosts calls and complains about its own clock, not yours. It’s a red herring we deliberately kept loud — ignore it and hunt for real [error] lines instead.
