Service Troubleshooting

Service-level failures that don’t have a one-line fix. Each section earned its place through a real outage that hid behind a cheerful green probe — the kind of bug that smiles at the watchdog while quietly dropping every fifth request for an hour. The main Troubleshooting page keeps the universal infrastructure scenarios; this annex carries the ones a few clicks down the diagnostic tree, where the fault lives in the gap between two services that have technically never been formally introduced.

VM Can Reach OpenClaw But Not Local Models

Symptom: The VM can talk to the Mac gateway on 10.10.10.1:1977, but model calls to 10.10.10.1:1337 or 10.10.10.1:1234 fail.

That means the VM bridge exists, but the model-serving side of the Mac has drifted. Usually one of two things is true:

1. The MLX model server is down or bound incorrectly.
2. The LM Studio bridge listener on 10.10.10.1:1234 is gone.

Check from the VM:

ssh openclaw "curl -fsS http://10.10.10.1:1337/v1/models | jq '.data | length'"
ssh openclaw "curl -fsS http://10.10.10.1:1234/v1/models | jq '.data | length'"

Check on the Mac:

curl -fsS http://127.0.0.1:1337/v1/models
curl -fsS http://127.0.0.1:1234/v1/models
lsof -nP [email protected]:1234 -sTCP:LISTEN

Fix:

# Re-run the VM startup path to restore the bridge surfaces
bash ~/.openclaw/scripts/vm-autostart.sh

If 127.0.0.1:1337 is down too, the MLX server itself is the problem, not the bridge. Fix the model server first, then re-run vm-autostart so the VM-side path matches reality again.

MLX Server Returning 503 (sanctum-idle Port Conflict)

Symptom: Local model requests fail with 502 All models failed. Last error: 503 http://10.10.10.1:1337/v1/chat/completions. The MLX server process is running but returning empty 503 responses.

Root cause: Two LaunchAgents competing for the same model server:

• com.sanctum.council-mlx starts the MLX server directly on 0.0.0.0:1337
• com.sanctum.idle-mlx runs sanctum-idle, which listens on 10.10.10.1:1337 and expects to manage the MLX server on 127.0.0.1:8900

When both are active, council-mlx binds MLX directly to port 1337. The sanctum-idle proxy still accepts connections on 10.10.10.1:1337 but its backend on port 8900 is empty — nothing is listening there. Every request gets a 503.

Diagnosis:

# Check for the conflict — two processes on port 1337 is the giveaway
lsof -i :1337
# If you see BOTH a Python/MLX process AND a sanctum-idle process, that's the bug

# Confirm nothing on 8900 (where idle expects the backend)
lsof -i :8900
# Empty = confirmed conflict

Fix:

# 1. Unload the conflicting agent (stops the process AND removes from launchd)
launchctl bootout gui/$(id -u)/com.sanctum.council-mlx

# 2. Permanently disable it so it never loads again at boot
launchctl disable gui/$(id -u)/com.sanctum.council-mlx

# 3. Kill any orphaned MLX process still on port 1337
kill $(pgrep -f 'mlx_lm.server.*--port 1337') 2>/dev/null

# 4. Restart idle-mlx so it manages the lifecycle properly
launchctl kickstart -k gui/$(id -u)/com.sanctum.idle-mlx

Caution

launchctl disable only prevents the agent from starting at next boot — it does not stop a currently running instance. You must use launchctl bootout first to actually unload and terminate the running service. Without bootout, the orphaned MLX process will keep squatting on port 1337 with PPID 1 (reparented to launchd).

Verify:

# Should show only sanctum-idle on 1337
lsof -i :1337

# Send a test request — idle will wake the model (may take ~30s first time)
curl -s http://10.10.10.1:1337/v1/models

Caution

com.sanctum.council-mlx is the legacy direct-launch agent. com.sanctum.idle-mlx is the replacement that adds idle shutdown (300s timeout) and on-demand wake. They cannot coexist. Keep idle-mlx, disable council-mlx. The model is the same, the port is the same, you just gain RAM reclamation when nobody is using inference.

Sanctum Proxy Missing API Keys After Manual Restart

Symptom: Claude Code requests fall through to deepseek-v3 or other fallback models instead of reaching Anthropic. The proxy is running but all Anthropic requests fail silently.

Root cause: The proxy binary was started directly (./target/release/sanctum-proxy) instead of through the LaunchAgent. The launcher script (~/.sanctum/scripts/proxy-launcher.sh) injects API keys from macOS Keychain. Without it, ANTHROPIC_API_KEY, OPENROUTER_API_KEY, and GEMINI_API_KEY are all empty.

Diagnosis:

# Check the launcher log — look for "anthropic=yes"
tail -5 ~/.openclaw/logs/sanctum-proxy-launcher.log

# If the last entry doesn't show key loading, the proxy was started manually

Fix:

# Always restart through the LaunchAgent, never the binary directly
launchctl kickstart -k gui/$(id -u)/com.sanctum.proxy

Danger

Never run sanctum-proxy directly from the command line in production. The binary has no way to access Keychain on its own — it relies on environment variables that only the launcher script provides. Direct execution means zero API keys, which means every cloud provider request fails and the fallback chain burns through alternatives until it lands on a local model or gives up entirely.

Fallback Chain Dead End (council-heartbeat)

Symptom: Heartbeat or briefing requests fail with 502 even though remote providers are healthy.

Root cause: The model’s fallback chain only contains other local models on the same server. If that server is down, every fallback also fails.

Example: council-heartbeat originally had only council-mlx as a fallback — both pointing at http://10.10.10.1:1337. When the MLX server was down, there was no escape route to a remote provider.

Fix: Ensure every local model has at least one remote fallback in config.yaml:

fallbacks:
  council-heartbeat:
    - council-mlx        # same local server (fast path)
    - nemotron-free      # remote escape route (OpenRouter)

Tip

Rule of thumb: every fallback chain should end with at least one model on a different provider than where it started. Local-only chains are a single point of failure. A free OpenRouter model like nemotron-free or minimax-m25-free costs nothing and prevents total blackout.

Holocron App Starts Black

Symptom: /Applications/The Holocron.app launches, the window appears, and then all you get is a black rectangle contemplating its choices.

The browser dashboard can still be healthy while the packaged Electron shell is busy sabotaging itself. They are related, not identical.

Check:

ps -ef | rg '/Applications/The Holocron.app/Contents/MacOS/The Holocron'
tail -50 ~/.openclaw/logs/living-force.log
tail -50 ~/Library/Application\ Support/the-holocron/logs/main.log 2>/dev/null

Common root cause: run_sanctum.sh used an overly broad process cleanup rule:

pkill -f "the-holocron"

That matched Electron helper processes via the user-data path and killed the renderer just after launch. Technically precise. Spiritually deranged.

Fix:

# Only target Holocron dev/Vite processes, never the packaged app
pkill -f '/Users/neo/Projects/the-holocron/.*vite' || true
pkill -f 'vite --host 127.0.0.1 --port 3333' || true

# Reinstall the current tested app bundle
cd /Users/neo/Projects/the-holocron
npm run update:app

Caution

If you use pkill -f with a vague substring around Electron, you are delegating process selection to chaos. Chaos is enthusiastic but not detail-oriented.
