Firewalla Purple → Gold Pro Migration

The Purple has guarded this haus for a year and a half. It paused kid phones. It blocked curfew-hour YouTube. It ran every screen-time rule we asked of it, without a reboot we didn’t schedule ourselves. It also spent those months quietly dropping flowsummary bytes — which is why we built an ARP fallback and a drift sentinel to compensate for a router that worked exactly well enough to lie. Tomorrow a Gold Pro arrives with ten times the CPU, four times the RAM, and — if the SDK cooperates — actual per-host flow data. This is the runbook for swapping it in without taking Albert’s bedtime offline for longer than a reboot.

Before the box arrives

First, photograph what already works. Run the capability probe against the current Purple so we have a baseline to diff against:

~/.sanctum/scripts/firewalla-probe/firewalla-sdk-probe.sh [email protected] \
  > ~/.sanctum/scripts/firewalla-probe/capabilities-purple-baseline.json

The baseline lives in the repo as capabilities-purple-baseline.json. It is the answer key. Tomorrow’s Gold Pro run writes capabilities-gold-pro.json, and diff tells us which new connectors the Firewalla bridge can finally support.

Then export the live policy state, so nothing hand-configured in the Firewalla app gets lost:

~/.sanctum/scripts/firewalla-export.sh
# Writes ./firewalla-export/$(date +%Y-%m-%d)/ with hosts.json, policies.json,
# dns.json, keys.tar.gz, screen-time.db, and the full bridge config.

The swap

1. Unbox + physical install. Gold Pro in the same spot the Purple lives, same WAN + LAN ports. Don’t power it yet.

2. Back up the current bridge keys. The SDK authenticates against the box by key pair; the Gold Pro gets a new pair and the old one becomes a paperweight.

   ssh [email protected] 'tar czf ~/Backups/firewalla-keys-purple-$(date +%Y%m%d).tgz -C ~/.openclaw firewalla/keys'

3. Power the Gold Pro. Wait for the Firewalla mobile app to discover it. Pair it (same cloud account, new device). Walk through the firmware update if prompted.

4. Transfer the rule set. The mobile app has a “Transfer from another Firewalla” flow. Use it. Migration preserves host names, device groups, ACLs, DNS policies, and most screen-time rules. Verify by scrolling the device list — 107-ish known MACs should all be there with their existing names.

5. Pull the Gold Pro’s new keys.

   The bridge needs the new box’s etp.public.pem, etp.private.pem, and group.json. Copy them off it via the Firewalla app’s “Export to Developer SDK” flow:

   # On the MacBook, then push to the Mini
   scp ~/Downloads/gold-pro-keys/etp.*.pem [email protected]:~/.openclaw/firewalla/keys/
   scp ~/Downloads/gold-pro-keys/group.json [email protected]:~/.openclaw/firewalla/keys/

6. Update the bridge’s local IP if it changed. Gold Pro often takes 192.168.1.1; if your old Purple used a different one, update the local_ip key in group.json.

7. Restart the bridge.

   ssh [email protected] 'launchctl kickstart -k gui/$(id -u)/com.sanctum.firewalla'

   Watch for “SDK initialized successfully” in ~/.openclaw/logs/firewalla-bridge.log. If it errors on auth, re-check the key files and group.json paths.

8. Probe.

   ~/.sanctum/scripts/firewalla-probe/firewalla-sdk-probe.sh [email protected] \
     > ~/.sanctum/scripts/firewalla-probe/capabilities-gold-pro.json
   diff ~/.sanctum/scripts/firewalla-probe/capabilities-purple-baseline.json \
        ~/.sanctum/scripts/firewalla-probe/capabilities-gold-pro.json

   The diff is the answer to “which connector do we ship next?” See the decision tree below.

9. Run the existing regression gates.

   tests/test-screen-time-enforcement.sh  # 18 PASS
   tests/test-drift-sentinel.sh           # 10 PASS
   tests/test-activity-tracking.sh        # 10 PASS

   If any gate fails, roll back (below) and investigate before proceeding.

What to hope for

The diff is a wish list with four possible answers. Each one points at a different connector, and the probe decides which:

Probe finding	What it means	What we do next
/hosts flowsummary has non-zero bytes	FirewallaBridgeConnector (byte-delta) finally produces data	Enable it; Albert’s daily minutes start accumulating immediately
/flows returns records	Per-destination data is available	Ship FirewallaFlowConnector — minutes bucket into YouTube / Crunchyroll / Roblox automatically
/live-stats returns {throughput, activeConn}	Real-time data for the panels	Optional upgrade for the Holocron dashboard’s live view
No change vs Purple	SDK is the same on both models	Fall back to DNS-tail or MSP cloud connector

Rollback

This is not a one-way door. The Purple is still in the box, and it still has its keys. Restoring is three commands:

# Plug the Purple back in, restore the old keys, restart the bridge
ssh [email protected] '
  tar xzf ~/Backups/firewalla-keys-purple-20260420.tgz -C ~/.openclaw/
  launchctl kickstart -k gui/$(id -u)/com.sanctum.firewalla
'
~/.sanctum/scripts/firewalla-probe/firewalla-sdk-probe.sh [email protected]  # should match the baseline

Screen-time enforcement, drift-sentinel, and activity tracking all keep working on the Purple. Nothing gets worse by trying.

Caution

If the Gold Pro migration wipes the Purple’s device groups (has happened on older firmware), the app-assisted transfer will land them as “new” devices. The drift-sentinel will notice and fire. The fix is manual: re-assign the groups in the Firewalla app. Takes five minutes and is the only known sharp edge in the transfer flow.

Why we bothered

The Purple did everything we asked on the enforcement side. The silent-success bug, the ARP fallback, the drift sentinel — all of it exists because the Purple works exactly well enough to fail in interesting ways. The Gold Pro upgrade isn’t about reliability. We fixed that in software. It’s about the data plane. A screen-time system that can tell you a kid has been on the network for four hours is half a system. The other half is knowing, per minute, which of those hours was Crunchyroll and which was Roblox. The Gold Pro promises that half.

Whether it keeps the promise is an empirical question. The probe is the experiment. Until it runs, the Gold Pro is just a better-looking box that does exactly what the last one did.
