The doctor that fainted at every diagnosis

The doctor that fainted at every diagnosis — a technical pencil sketch in the Sanctum docs house style, hand-drawn black-and-white, wide 16:9. A doctor in a white coat has fainted sideways on the floor of a small haus, his stethoscope unplugged and trailing into a dark gap between the floorboards. Six cracked wall gauges behind him have their glass faces turned away, readings invisible; a clipboard by his hand reads only 'exit 4'. Tommy the Abyssinian sits on a drafting table and watches the gap in the floorboards, not the doctor; one subtle amber halo rises from the open gap.

The sweep opened with a confident, wrong alert: Yoda Signal did not self-assemble after boot. Right instinct, wrong diagnosis. The gateway was crash-looping, yes, but the consumer unit it named didn’t exist, and the real break was upstream of all of them. Six controls across two machines were blind, and the thread connecting them was not obvious from any single one. Each had to be found before the pattern showed.

Tommy — the haus’s late Abyssinian, now its only force-ghost — would have gone straight to the gap in the floorboards. In the sketch he ignores the fainted doctor and the six dead gauges and watches the dark seam where the readings fell. Every one of these controls could say exactly why it had failed. Each of them said it into a place nobody was reading.

openclaw-gateway was at 6,830 restarts and climbing, every instance exiting 4/NOPERMISSION. The unit file ran it through sops-start.sh, a wrapper that decrypts secrets.enc.yaml — the VM leg of the secrets trifecta — and maps values to service env vars before exec-ing the real binary. A direct node invocation ran clean — ready in twelve seconds, Signal channel attached. The wrapper was the difference.

The wrapper asked sops for --output-type dotenv. On 2026-07-08 a nested value landed in the secrets file, and sops’s dotenv dumper cannot flatten a structure — it exits 4 with a message on stderr. The wrapper redirected that stderr to /dev/null:

Terminal window
"$SOPS" -d --output-type dotenv "$SECRETS_FILE" > "$ENVFILE" 2>/dev/null

So sops died, the wrapper died, systemd recorded NOPERMISSION (exit 4, the sops code, mistaken for a permissions fault), and restarted it five seconds later. Forever. Four services share that wrapper — gateway, graphiti-server, firewalla-bridge, health-ingester — and all four were silently crash-looping the same way, distinguished only by which one noticed first.

The verifier that couldn’t see its own subject

Section titled “The verifier that couldn’t see its own subject”

The vault inbox was repeating an alert every three minutes: identityverifierblind — only 1/8 agents could be verified (partition / VM unreachable). The archive held weeks of the same message. Eight signed agent identities are checked on a sweep — jocasta locally on the MBP, seven Jedi workspaces inside the Lima VM on manoir — fetched over ssh manoir tailnet.ts.net "limactl shell sanctum-vm -- ...". The MBP-to-manoir hop was fine. The manoir-to-VM hop returned command not found: limactl.

limactl lives at /opt/homebrew/bin/limactl. The verifier’s ssh runs a non-interactive shell, and non-interactive zsh on manoir never had /opt/homebrew/bin on its PATH. The ~/.zshenv — the file that runs for every shell, interactive or not — sourced cargo and configured the SOPS age key but never added Homebrew. The 2026-06-19 hardening rewrite of the verifier had started calling bare limactl, and from that day every sweep silently failed the VM leg and reported 1/8.

The fix was one line in manoir’s ~/.zshenv:

Terminal window
export PATH="/opt/homebrew/bin:$PATH"

After the line landed, a kickstarted sweep wrote 8/8 to the heartbeat. Twenty days of blindness had hidden nothing — the identities were intact — but a control that cannot prove it is enforcing is down, not open.

A builder session hardened proxyd — no unwrap/expect in the hot path, per-model TTFB timeouts, a panic hook that logs file:line. The binary was copied to ~/.sanctum/bin/proxyd. The deploy note said: sudo launchctl kickstart, then cp, then kickstart again. Two gaps hid in that recipe.

First, sudo from this environment needs a terminal password it cannot get. Second — and this was the real one — the LaunchDaemon doesn’t exec the binary directly. It execs proxyd-launch, a wrapper that loads provider keys from a secrets dir and then execs a BINARY whose path is hardcoded in the wrapper. That path still pointed at the old ~/Projects/sanctum-rs/target/release/proxyd. So the hardened binary sat at ~/.sanctum/bin/proxyd unused, and any restart would have relaunched the pre-hardening build.

The deploy doctrine says the system LaunchDaemon’s KeepAlive respawns after a kill <pid> — no sudo needed. So the fix was: repoint the wrapper’s BINARY= line, kill the old PID, let KeepAlive bring up the new one through the corrected wrapper. Verified by e2e — a chat completion through council-mlx returned OK, and the singleton guard that replaced an old mutual-kill pkill fired correctly during the respawn race.

com.sanctum.council-drift had exited 1 on every hourly run for twenty days. Two deploy files had fallen behind prod: the com.sanctum.mlx.plist (repo described the old 27B-only config; prod runs the 35B cathedral with a 27B draft, memory bumped) and council-drift-check.sh itself (prod had a redact_secrets improvement that reports drift on structure, never on the secret value). In both cases prod was the intended state, so the fix was reconcile prod→repo.

sanctum-plist reconcile captures the live plist back into the repo and commits. The first commit blocked: a no-hardcoded-ip pre-commit hook flagged the 10.10.10.1 vmnet bridge anchor. The raw capture had dropped the inline ip-allow comment that justifies that literal — the comment is what the hook requires. Restoring it in the repo wasn’t enough; prod and repo had to match byte-for-byte, so the same harmless comment was added to the prod plist. A comment-only edit to a running plist doesn’t affect the live process (launchd only re-reads on reload), so it was safe.

A stale ironclaw SSH host entry — a Lima VM on 127.0.0.1:3100 that no longer exists on manoir (only sanctum-vm is running) and was never part of the verifier’s eight — was pruned from ~/.ssh/config. And a fresh bert-cli mTLS client cert was minted into ~/.sanctum/certs/clients/ so the CLI can probe the --no-plain servers on :1337/:3301/:4040. The 000 responses that opened the LLM audit were a missing-client-cert artifact, not dead services — the servers were healthy all along, and we had simply been knocking without a key.

Six controls. A gateway crash-loop, a deaf identity verifier, a proxy pointing at its old self, a twenty-day drift, a dead SSH alias, a missing client cert. The first three share a cause that none of them advertises: the failure was diagnosable, but the diagnosis was sent somewhere nobody looked. sops wrote it to /dev/null. The verifier’s limactl: command not found went to the same place. The proxy’s stale path hid behind a wrapper that looked correct on its surface. It is the same shape as seventeen days of silent failure: a control that suppresses the channel it uses to explain itself is, in the doctrine of the fifth guardian, down — not open.

The fix for each was small. Finding each was the work — which came down to looking in the gap between the floorboards, where the diagnoses had been falling all along, and where the cat had been staring the whole time.
