2026-05-14: The Cathedral Doubled Itself

The cathedral’s coder was at 24.1 tok/s. The plan for the night was modest — close the gap to LM Studio’s published top-end (25–35 tok/s on M4 Pro), tidy up, go to bed. What we actually had by morning: 24.1 → 50.3 on the essay benchmark, the same pattern shipped onto Yoda’s 35B inside one sitting, and a multi-hour wrong-answer rabbit hole that turned out to be a single MLX view-aliasing trap you defeat with a six-line + zero. Qui-Gon would have approved of the throughput and been appalled by the hours it cost.

The two fusions

Two passes, same shape. Both apply to any pair-or-triple of independent quantized linear projections that share an input — which is the cathedral’s hottest inner loop.

Phase 1A — fused QKV. sanctum-rs 8da9d33 concatenates q_proj, k_proj, v_proj weight tensors on the output axis, does one quantized_matmul over the combined [q_out + 2·kv_out, hidden/8] weight, splits the result back into Q, K, V on axis -1. Replaces three matmul kernel launches per attention layer with one. For Qwen2.5-Coder-14B-4bit that’s 96 saved launches per decode step — roughly 3 ms at the M4 Pro’s ~30 µs/launch.

Phase 1B — fused gate+up MLP. sanctum-rs adfbf76 applies the same recipe to SwiGLU’s gate_proj and up_proj (the two parallel matmuls before SiLU+multiply). Same launch-count savings, slightly cleaner code because there’s no additive bias path to handle.

Both pieces shipped in PR #16 and merged together — the LoRA Phase 4/5 stack on the same feature branch came along for the ride. The live coder cathedral on :1338 was reloaded with the merged binary and started serving at 35–50 tok/s on freeform completions of 256 tokens. That is where a lesser night would have stopped.

The trap that ate three hours

The fusion math is trivial. The integration is not. After the first commit the cathedral produced output like "The capital of France is!!!!!!!!!!!". The first token was right; everything after collapsed into a single repeated token. A model that knows the answer and then screams it is a special kind of insult.

The bisect harness (services/sanctum-mlx/src/bin/qkv_fuse_bisect.rs, also shipped in PR #16) ran five tests in order of increasing rigor: single-layer projection compare, single-layer attention forward, full model prefill, varied-magnitude L=1 projection, and finally a 20-step decode loop with populated cache. The first four passed byte-for-byte. Only the fifth caught the bug, and it caught it on the very first decode step.

The cause was mlx_rs::ops::split_sections. After concatenating Q, K, V weights and one matmul, the obvious next step is to call split_sections to get back three tensors on axis -1. The function returns three views into the contiguous matmul output — but only the Q view has zero storage offset. The K view has offset q_out; the V view has offset q_out + kv_out. The K and V views inherit the source array’s stride pattern, which is [L·total, total, 1], not the [L·kv_out, kv_out, 1] that downstream code expects.

Inside Attention::forward, the next operations are reshape and transpose, both of which are views. They never materialize. Then RoPE consumes them with a non-zero cache.offset(). RoPE reads the K and V tensors stride-aware, but those strides are wrong — the read pointer ends up walking past the end of the K slice and into V (or further). The first decode step exposes it because that’s the first step where cache.offset() > 0 and the read pattern stops accidentally lining up.

The fix is array.add(&zero)? on each split part. The arithmetic kernel is what forces MLX to allocate a fresh row-major buffer and copy the values into it. Three other MLX ops that the docs suggest should work — mlx_contiguous, mlx_copy, and reshape to the same shape — all silently keep the view. We verified each as a negative result and pinned them in the source comments, so the next reader inherits the map instead of the maze.

What 50 tok/s actually looks like

On Qwen2.5-Coder-14B-Instruct-4bit with both fusions live:

	tok/s	Notes
Cascading PLD baseline	24.1	what we had at session start
LM Studio published range	25–35	M4 Pro, same model, public benchmarks
M4 Pro theoretical decode ceiling	~39	weight-bandwidth limited
Coder live, freeform story (256 tok)	35.3	parity with LM Studio top
Coder live, essay (256 tok)	50.3	beats theoretical ceiling via PLD compounding

The essay number is above the pure-decode ceiling because prompt-lookup decoding finds runs of n-grams the model is about to emit and verifies them in parallel against the target. On repetitive prose the verification rate climbs and the effective throughput crosses the per-token bandwidth limit. LM Studio doesn’t have PLD, so its ceiling is the bandwidth one. We are not faster silicon; we are faster because we stopped asking the silicon to do work it could skip — which is the whole Carmack lens.

The 35B port

The other half of the title. The qwen3_5_moe model on the Mini (Qwen3.6-35B-A3B-4bit on :1337) is a hybrid: 10 layers of standard FullAttention with RoPE, 38 layers of LinearAttention running an SSM scan via the existing gated_delta_kernel. Only the FullAttention layers have the q/k/v projection pattern that Phase 1A targets.

sanctum-rs 865bc24 ports FusedQkvProj to vendor/mlx-rs/mlx-lm/src/models/qwen3_5.rs. The math is identical; the only twist is that qwen3_5’s q_proj has output n_heads · head_dim · 2 (queries + output gate combined), so the Q half of the fused output is twice the size you’d expect. The downstream code that splits Q into queries and gate operates on the fused output unchanged.

The bisect, services/sanctum-mlx/src/bin/moe_qkv_fuse_bisect.rs, runs the same 20-step decode-with-populated-cache test against the 35B’s Qwen3_5MoeInnerModel.forward. It passed byte-for-byte on all 20 steps — the trap that took three hours to find on the 14B did not need re-finding on the 35B. The pattern transferred clean. That is what a good bisect buys you: the second time, you pay nothing.

Yoda’s cathedral was reloaded with the new binary and SANCTUM_MLX_FUSED_QKV=1. The log shows 10 qwen3_5: fused QKV projection built lines (one per FullAttention layer), the smoke test correctly answers "The capital of France is **Paris**.", and the decode rate sits at 56–60 tok/s on 256-token freeform — though the 35B is so much smaller in active parameters than its weight count suggests (MoE with ~3B active per token) that the headline number isn’t directly comparable to the dense 14B. Yoda got faster overnight and, characteristically, said nothing about it.

The kernel that worked and the kernel that won’t

The natural next step after Phase 1A+1B is a custom Metal kernel that does split+materialize in one launch, eliminating the three + zero arithmetic kernels. The work is on the feat/cathedral-phase2-fused-rope branch.

The kernel is correct in isolation (bisect’s DIRECT kernel sanity check is byte-exact) and live-correct if an eval barrier is placed after every call. The barrier is the problem: MLX’s lazy graph doesn’t auto-track custom-kernel outputs as dependencies, so without eval the downstream reshape → transpose → RoPE reads stale memory. With it, the forced sync costs more than the two saved launches buy back — net -10 tok/s versus the + zero path that MLX was already overlapping with other GPU work. The elegant kernel loses to the ugly one because the ugly one lets the scheduler breathe.

Three things that look like fixes but aren’t: mlx_contiguous(a, false) keeps stride-1-on-last-axis views with non-zero offsets; mlx_copy(a) has the same view-keeping behavior; eval-once-at-end-of-attention-block instead of per-kernel breaks even the unfused path. The real fix is upstream in MLX’s fast::metal_kernel graph-tracking, not in our integration code — a hole to leave for a night that can afford it.

What’s in main now

• Phase 1A (FusedQkvProj for qwen2) — live on coder :1338
• Phase 1B (FusedGateUpProj for qwen2) — live on coder :1338
• Phase 1A port to qwen3_5_moe FullAttention — live on Yoda :1337 via the feature branch’s deployed binary
• Two regression-catcher bisects (qkv_fuse_bisect, gate_up_fuse_bisect) plus a third for the MoE port (moe_qkv_fuse_bisect)
• The view-aliasing trap pinned in source comments + three memory notes so the next session doesn’t re-discover it

The remaining headroom is Phase 2 proper (custom MSL with stream-aware graph tracking) and possibly fused RoPE, but both require an MLX upstream understanding the night couldn’t justify. The 24 → 50 tok/s win on dense Qwen plus the byte-perfect port to the MoE is a load-bearing checkpoint either way — the kind you can build the next night on top of, which is the only kind worth shipping. For the two-token cousin of this bug, see the kernel that needed two tokens.

Note

The bisect harnesses are the most reusable part of this work. They ship next to the code they validate, run in under thirty seconds against a real model snapshot, and catch the only bug class that matters for fusion correctness — the one where four shallower tests pass and the deepest one fails. Anyone porting this pattern to a new model should clone the bisect first and the fusion second. The bisect is the patrol: you run it before you trust the morning.
