2026-05-22: The Cathedral Could Not Read Long

The cathedral — the council’s LLM, Qwen3.6-35B-A3B served by sanctum-mlx on :1337 — has a model card that says max_position_embeddings: 262144. It is the model Qui-Gon leans on for infra work. For its entire life nobody had asked it for more than a few thousand tokens. We built the long-context eval harness to change that: needle-in-a-haystack plus a mini-RULER probe set, trending retrieval quality as the prompt grows. It was the first thing we ever pointed at the cathedral at length, and it caught a real bug on its very first real run.

1. The bug the harness found

The harness assembles a haystack, hides a needle, asks the cathedral to recall it, and scores the answer. At 4K tokens: clean. At 16K: clean. Above roughly 25,540 tokens the cathedral returned an empty completion. Not a wrong answer. Not a truncated one. Zero generated tokens.

The request did not error. The server logged a 200. The prefill counter ran the full prompt — every token of context was consumed. Then the decode loop emitted exactly one token, the end-of-sequence marker, and stopped. The cathedral read the whole library and answered with a closed book.

This is the worst shape a bug can take: a success status, a plausible response object, nothing inside it. Without the harness you would have met it months later as “the council gets weird on long documents” — a vibes report with no line number, the kind that costs a week to reproduce.

2. Two wrong turns

The first suspect was TurboQuant — the cathedral’s 4-bit V-cache quantization. A length-dependent failure that produces no output smells like a dequant kernel reading past a buffer once the KV state is large enough. The test was direct: rerun the same oversized prompt on the plain Fp16 attention path, TurboQuant disabled. It failed identically. Same threshold, same empty completion. TurboQuant was innocent — disproven, not argued away.

The second suspect was the fused attention kernels, which sanctum-mlx appeared to gate behind environment toggles. The theory: a fused path enabled at length, disabled below it. The test was to read the build, not the env. The env vars were vestigial — leftovers from an older bring-up. Kernel fusion is always-built; there is no toggle to flip and no length-gated path to blame. Disproven again.

Two hypotheses, both plausible, both killed by a test instead of a guess. The bug was lower than either.

3. The root cause, proven to the byte

Qwen3.6-35B-A3B has head_dim = 256.

MLX’s fused flash causal-SDPA kernel — the fast path for scaled-dot-product attention with a causal mask — supports head_dim of 64, 80, or 128. Nothing else. A model with head_dim = 256 does not match, so full-attention prefill silently falls back to an unfused implementation: a plain matmul that materializes the entire attention-score buffer before the softmax.

That buffer has shape [B, 16, L, L] in fp32 — sixteen heads, query length by key length. Its size is 16 · L² · 4 bytes. The numbers do the rest:

Prompt length L	[B, 16, L, L] fp32 buffer	vs. Metal limit
16,384	17.18 GB	under
24,000	36.86 GB	under
25,540	41.74 GB	right at the edge
25,600	41.94 GB	over
32,768	68.72 GB	far over

Metal has a hard maxBufferLength of 41.75 GB on the M4 Max. At L ≈ 25,540 that single attention-score buffer crosses it. The allocation fails. The prefill cannot complete. The request dies — and the decode loop, handed a model state that never finished its prefill, emits end-of-sequence as the only thing it can.

Decode survived all along because decode runs one query token against the full KV cache: head_dim = 256 is supported by the fused kernel when query length is ≤ 8. Prefill processes the whole prompt as one wide query block — thousands of tokens — the case with no fused kernel.

The bug is not in the cathedral’s code. It is a property of the model’s geometry meeting a kernel’s support matrix. But it is the cathedral’s bug to fix.

4. The fix

Chunk the prefill’s query axis.

Instead of one attention call over a query block of length L, the prefill now iterates the query axis in blocks of 2048. Each attention call materializes a bounded [B, 16, 2048, L] buffer — at most 16 · 2048 · L · 4 bytes, linear in L, not quadratic. The 41.75 GB ceiling is never approached.

The change is numerically bit-identical to the unchunked path. Softmax is computed per row; a query row’s attention distribution depends only on that row and the keys, never on sibling query rows, so splitting the query axis changes nothing arithmetically. The causal mask offset is preserved per block — block k starts at query position k · 2048, and its mask is shifted to match, so each query token still attends to exactly the keys it should and no others.

One change covers both attention implementations the cathedral runs: the dense full-attention layers and the mixture-of-experts path share the same prefill attention call, so chunking it fixes both at once.

Shipped in sanctum-rs 5731769. The cathedral now serves its full advertised 262,144-token context. The harness, rescoped down to 4K/16K while the bug stood, can have its longer rungs restored.

The doctrine

An MLX model whose head_dim is not 64, 80, or 128 has no fused causal SDPA. Its prefill silently falls back to an unfused matmul that goes quadratic in memory, and it will OOM at length on a buffer the size limit forbids. Decode hides it, because decode’s query length is small enough to keep the fused kernel. The failure waits for the first long prompt.

The second doctrine is about the harness. The long-context eval was built to trend retrieval quality — to catch slow regressions over weeks. It earned its keep in a different way: it caught a hard defect on day one, a bug the performance-tuning work of the last fortnight had walked straight past because none of that work ever sent a prompt long enough to trip it. A benchmark’s stated job is to measure. Its first job is to be the first caller who asks the hard question.

You cannot regress a length you never test. You also cannot discover a length you never test.

What is next

• Restore the harness’s 64K and 128K rungs now that the cathedral serves them — a one-line change to the size table that the >25K bug had forced down to 4K/16K.
• Watch whether the chunked prefill costs measurable throughput on short prompts. The block loop adds iteration overhead; for prompts under one block (2048 tokens) it is a single iteration and should be free, but the canary’s prefill timing will confirm.
• An upstream note to mlx-rs / mlx: the fused causal-SDPA head_dim support matrix deserves a documented fallback warning. A model author picking head_dim = 256 has no signal that prefill will go quadratic until it OOMs.
