Single-NAT: modem → Firewalla → Wi-Fi, seamlessly

You forwarded the port. You triple-checked the rule, restarted the box twice, and the connection still dies somewhere in the dark between the internet and your couch. Here’s the culprit: two routers out there both lowkey convinced they own the front door — your ISP’s hub and your own router — each translating your traffic, each pointing at the other like a Habs bench after a blown third period. That’s double-NAT: two seams cosplaying as a network. Single-NAT collapses the whole mess to exactly one seam — your Firewalla holds the public address, your hub drops to a dumb bridge, and everything downstream answers to a single policy point.

What single-NAT is, and what it actually buys you

A NAT is the seam where your private LAN gets translated to a public address. Run two of them — ISP hub and your router — and you have double-NAT: two translation tables, two firewalls, two devices that each think they own the edge. Inbound rules have to be punched through both. Your IPS sees a private address where the real client should be. Port-forwards chain awkwardly or break.

Single-NAT puts your router on the public IP directly. One translation table, one firewall, one place to forward a port, one honest view of who’s connecting.

It is not a speed upgrade — we measured

The internet will tell you double-NAT “caps your throughput.” On modern gear it does not: NAT topology changes throughput by zero. We chased that myth on an 8-gig Bell line and it cost us an evening — the full autopsy is in The Speed Test That Cried Slow. Do this for clean inbound rules, public-IP ownership, and a single policy seam. Do not do it expecting a faster speedtest.

Before you flip

You need	Why
An Advanced-DMZ-capable hub (Bell / Sagemcom)	Single-NAT needs the hub to hand its one public lease to your router instead of keeping it
A router-mode Firewalla (Gold Pro field-proven)	The device that takes the public IP and becomes the single NAT
An out-of-band path to the Firewalla	The recovery gate. If the LAN collapses mid-flip, this is how you drive the rollback

The out-of-band path is non-negotiable, and it has a trap: it must not ride the LAN it is about to take down. A Tailscale node sitting on the 10.x LAN dies with that LAN — it looks like a safety net and isn’t. Run the cutover from the hub’s own Wi-Fi, a cellular hotspot, or a node whose path is DERP-relayed over the WAN. The preflight gate checks for this; let it.

The one-command flip

sanctum net single-nat is dry-run by default — bare, it prints the staged plan and writes nothing to any device. --apply is what actually fires, and it is attended-only: there is no cron path, by design. Whole-haus WAN surgery is structurally a thing you watch happen.

1. Read the plan.

   sanctum net single-nat

   Seven staged steps, each rollback-safe. Read them. The worst case at any stage is plain double-NAT — online, just not yet armored.

2. Move your operator host off the LAN, confirm the out-of-band path, then fire.

   sanctum net single-nat --apply

   It snapshots the hub baseline, then stops at the one human gate: it confirms the Firewalla is reachable out-of-band before touching the WAN, and aborts cleanly if it isn’t. From there it drives every stage — WAN to DHCP, enable Advanced DMZ, reboot the hub to re-key the lease, renew the Firewalla, install the armor, verify — and on any failed verify it auto-rolls-back to double-NAT and tells you why.

3. Reverse it any time.

   sanctum net single-nat --rollback

   Disables the DMZ, re-leases DHCP, and lands you back on verified-online double-NAT in one command. The armor hook and sentinel stay installed but go inert — on a normal private lease they are a safe no-op.

The /32 armor and the poison-sentinel

Bell’s Advanced DMZ has a nasty habit: along with your public lease it hands out a 0.0.0.0/1 poison route — a single-bit netmask (128.0.0.0) wide enough to put a 76.x public IP and a 10.x carrier gateway on one wire. The side effect is brutal: that /1 swallows your entire 10.x LAN, the Firewalla decides every LAN address is a WAN neighbour, and routing quietly dies. The whole forensic is in The Slash-One That Ate the LAN.

The /32 armor is the fix the flip installs for you. It pins the WAN to a host route (/32) and strips the poison 0.0.0.0/1 from both the main routing table and every per-WAN policy table — because Bell plants it in both, and cleaning only main leaves the policy-table copy to re-break you. It also sets the WAN MTU to 1492 and clamps the MSS, closing the black-hole where ping passes and HTTPS doesn’t.

The catch is that Bell re-hands the poison route on every WAN lease renewal. So the armor isn’t a one-shot — it ships with a systemd poison-sentinel baked into the Firewalla’s boot hook that re-runs the strip on every renewal. The route comes back; the sentinel takes it off again, forever, without you.

The downstream router: Orbi in AP mode

For the Firewalla to be the single NAT, everything behind it must stop doing NAT. Put your Orbi (or any AP) in AP / bridge mode so it bridges Wi-Fi onto the Firewalla’s LAN instead of translating a second time.

AP mode changes how you reach the Orbi — not whether you can

An Orbi in AP mode shuts off its local SOAP service on port 5000, so the Netgear app can’t reach it on your LAN. But it doesn’t need the LAN — it manages the unit through Netgear’s cloud, which works as long as the AP itself has internet (a gateway and DNS). Starve the AP and the app shows it offline — that’s missing internet, not broken AP mode. The web admin at http://<orbi-ip> works on the LAN regardless.

One more new-user step that saves a confusing afternoon: set the Orbi’s management IP to DHCP, then give it a reservation on the Firewalla. DHCP means the AP actually receives a gateway and DNS, so it can still reach the internet for cloud login and firmware updates; the reservation means it always lands on the same address, so http://<orbi-ip> is a bookmark and not a scavenger hunt. The real trap is quieter than “no gateway”: an AP with a gateway but an empty DNS field still reads its internet as down — magenta, no cloud, no firmware — routing works, resolution doesn’t. DHCP hands it both; a static IP must set DNS to the Firewalla’s LAN address too, or you’ve built the trap by hand.

Verify, and how to back out

sanctum net check        # NAT topology: should now read "single"
sanctum net speedtest    # honest multi-stream throughput (NOT a NAT test)

net check is the read-only verdict — it should now say single with the Firewalla holding the public IP. net speedtest is there to confirm you didn’t lose anything, not to prove you gained speed (you didn’t — see the caution above). Run a real page load and a video stream too; small packets lie, large ones tell the truth.

To go back: sanctum net single-nat --rollback is the clean path. The blunt-instrument equivalent is disabling Advanced DMZ in the hub’s admin — the Firewalla loses its public lease, re-DHCPs to a private 192.168.2.x, and you’re on known-good double-NAT within a minute.

What to expect

	Single-NAT (Firewalla on public IP)	Double-NAT (hub + router)
Inbound / port-forwarding	One hop, one rule, clean	Punch through two devices
Public IP held by	Your Firewalla	The ISP hub
Throughput	Same — NAT count changes it by zero	Same
Bell poison /1 route	Stripped + self-healed every renewal	Not exposed (hub keeps the WAN)
Orbi / AP management	Web admin http://<orbi-ip>; Netgear app works via cloud once the AP has internet	Netgear app works (router still NATs)
Recovery if it goes wrong	--rollback, or disable DMZ → double-NAT	Already here

Tip

First run is the real cutover, and it’s meant to be watched. Be at a machine that survives the LAN, keep the Firewalla pairing recovery path within reach, and let the gate stop you if the out-of-band path isn’t honest. The armor is the net; the gate is the rope you check before you walk the wire.
