The Capacity Doctrine

A military-grade bulkhead door closing in front of a corridor full of heavy machinery, lit by a single amber warning light.

On 2026-04-23 the Mini kernel-panicked twice. On 2026-04-24 LM Studio stalled at 99 percent loading a model while the VM’s qemu process sat SIGSTOP’d for two hours in silence. Different symptoms, same disease: multiple memory-heavy services competing for the same unified RAM pool with no admission control. Each service trusted the kernel to find it space. The kernel, overwhelmed, either panicked or paused at random. We discovered the ceiling by hitting it.

The Capacity Doctrine is the immune-system answer: refuse bad loads up front instead of reacting to failures downstream.

Three Rules

Rule 1: Declare your weight

Every heavyweight service has a ram_budget_mb number in ~/.sanctum/capacity.yaml. No budget, no admission. Since 2026-10-03 the number is what the service typically holds while serving — its measured phys_footprint, rounded up to 256 MB — not its worst moment; Bert’s call was pragmatic, not the worst case. Loads and long prompts are transients, and the safety floor and macOS compression absorb them.

Rule 2: Admission gates every load on live memory

castellan on port 2189 gates every evictable load against three live kernel signals, never a static budget sum. First, the kernel’s own available figure — kern.memorystatus_level of physical RAM — minus the safety floor. Second, swap depth: with 3/8 of RAM in swap, admission refuses, because the kernel reports pressure NORMAL straight through deep swap. Third, the kernel pressure level, used as a one-way STOP veto. The pinned council is always admitted and is never a shed candidate. A shortfall returns HTTP 503 with the shed order, lowest-priority evictable first; an exclusive_with clash returns HTTP 409 with the blocking service name.

Rule 3: Nothing critical gets suspended

The council VM, sanctumd, sanctum-mlx, signal-cli, WindowServer are pinned via evictable: false in capacity.yaml. Castellan programs the kernel’s own arbiter: pinned services get jetsam band critical (190) and stay there. The active loop will never SIGSTOP them; the kernel itself spares them when memory pressure crests.

The Ledger Is Live

The admission ledger is not a state file that can drift from reality. On every /status or /services request — and before any /load/{svc} — the daemon re-scans ps output and reconciles against capacity.yaml. A service is loaded iff either:

its process_pattern regex matches some live command line, or
its loaded_check_cmd exits zero within two seconds.

This means the ledger self-corrects across daemon restarts, unclean exits, and manual kill -9 — there is no state to repair because there is no stored state to corrupt.

Pinned, Evictable, Exclusive

Both seats are pinned and resident today — the brain on :1337 and the backup brain on :3301, both live by Bert’s call — and the only evictable entry is a disabled experiment. The budgets are typical footprints, measured:

sanctum-mlx:
  ram_budget_mb: 21248         # Qwen3.8-27B brain, :1337 — typical, measured 21,025 MB
  priority: 100                # evictable defaults to false: pinned, never shed

mlx-coder:
  ram_budget_mb: 17152         # Muse-Glimmer-30B backup brain, :3301 — measured 17,148 MB
  priority: 85

mlx-heretic:
  ram_budget_mb: 24000
  evictable: true              # disabled experiment; holds no reserve while down
  priority: 20

exclusive_with is still enforced at admission, but it is now reserved for genuine incompatibilities — a second resident 35B, say, that would OOM the box even when the arithmetic looks fine. Priority is the tiebreaker when the sentinel must choose a victim, and the pinned council is never one.

Four Layers Of Defense

Layer	Purpose	When
Kernel-as-arbiter	Program jetsam priority bands per-PID so the kernel itself shelters the pinned council and sheds the evictable coder	Every 2s via `memorystatus_control`; birth-floor via plist `JetsamPriority`
Admission	Refuse loads that exceed headroom	Before anything allocates
Monitor	Catch half-loaded states and signal-stopped processes	Every 2s tick — pinned-service probe, drift check, SIGSTOP scan
Recovery	Unstick what slipped through	`kill -CONT` on a stopped service; `unload_cmd + load_cmd` on a failed probe; for a pinned seat launchd has lost, a rescue that bootstraps its plist, because kickstart alone cannot (proven by the Castellan Heal Drill); all rate-limited to one rescue per service per 30 min with backoff after two failures in an hour; deadman SIGCONT if the keeper himself dies

The layers are independent. The kernel arbitration alone would miss admission cases where everything fits but the wrong thing got loaded. Admission alone would miss a runaway allocation that grew after load. Monitoring alone would miss the load that never should have started. Recovery alone is the old watchdog — it reacts too late. Together they form a control loop where every pathway back to a known-good state is explicit. The Castellan implements all four — see The Castellan for the daemon’s anatomy.

The CLI Is The Contract

The canonical way to load a heavy service is never launchctl kickstart … directly. It is:

castellan load <service-name>

The CLI posts to /load/{svc}. The daemon runs admission first and only then executes the service’s load_cmd, synchronously, returning 200 once the seat probes healthy. A refusal never reaches load_cmd: the CLI exits non-zero on the 503 or 409, remedy printed to stderr. Direct launchctl calls bypass admission — they’re permitted but discouraged, and the kernel-band layer will still steer jetsam toward the right victim if pressure crests.

Host Budget Math

Each host declares three numbers. The pool is derived:

hosts:
  cabane:                        # slug for the home-server role
    hostname: manoir.local       # the actual machine on that slug
    ram_physical_mb: 65536       # Mac Mini M4 Pro, 64 GiB unified
    ram_reserved_mb: 10240       # macOS + WindowServer + user apps
    ram_safety_mb: 4096          # hard floor — never fill below
    # pool_mb = 65536 − 10240 − 4096 = 51200 MB

The safety margin is non-negotiable. We don’t allocate into it even if admission math says we could — it’s the buffer that keeps the kernel’s own memory-pressure machinery working. Hit the safety margin and you’re in the territory where jetsam starts SIGSTOPping random processes, which is where the 2026-04-24 incident came from.

From Budgets To Live Memory

The first cut summed every service’s budget against the pool. On a healthy box that read deeply negative — a 40 GB council plus its peak reserve double-counted itself — and refused every legitimate load. The second cut read the kernel’s page counts but spent only the droppable pool, free + speculative + purgeable, and judged swap by the space left in swap files the kernel grows on demand. On 2026-10-05 that keeper was found logging Catastrophic every two seconds on a working Mini. The gate now spends the kernel’s own available figure and reads swap by depth. That is safe because the seats’ weights are Metal buffers, dirty memory the kernel never counts as available. If a seat ever maps its weights from disk again, that figure would call them reclaimable, and the droppable pool would have to come back — see the field note.

What This Replaces

Before the doctrine, capacity was a hope. Services started on reboot, the OS sorted it out, and when it didn’t, the watchdog noticed eventually. The 2026-04-23 kernel panic and 2026-04-24 freeze were both perfectly-preventable incidents — we had the information to refuse those loads, we just weren’t asking.

After the doctrine, capacity is a refusal. The admission controller can point at any service, at any moment, and say “not this one, not now, here’s why, here’s the remedy.” That is the Apple-like part. That is the military-grade part.

The system no longer discovers the ceiling by hitting it.
