Sanctum Gateway

Claude has no credentials, and no network of its own. Yet it needs to drop a tearsheet into the right SharePoint folder at Triptyq — in under two seconds, without ever holding a secret. This gateway is how it does that: a pluggable HTTP + MCP gateway on the Mac Mini that lets Claude push artifacts — memos, tearsheets, DD docs, transcripts — into SharePoint, or any future destination, with one self-contained call.

Three modules are live and HMAC-scoped — sharepoint (writes), m365 (reads), and tearsheets (renders a portco .docx) — with a fourth, slack, code-complete but dormant. Each is detailed below.

Naming

This is the gateway whose code lives at Ogilthorp3/sanctum-gateway and serves traffic at bridge.nepveu.name. The unrelated SQLite proxy documented in SanctumBridge shares no code, no traffic, and no install path with this gateway.

Goals

Our bar, before writing a line:

• Replace the Rube → Composio File Bridge recipe with a stable, owned path.
• One curl from Claude’s bash sandbox uploads a file to the right SharePoint folder, with metadata, in under 2 s.
• Same logic also reachable as MCP tools from claude.ai custom connectors.
• Adding a new destination is a module drop, not a service rewrite.
• Auth strong enough to survive a leaked HMAC secret OR a leaked CF token OR a tunnel misconfig — but not so heavy it slows the call path.

Architecture

Five middleware layers, one process. Each can short-circuit, and every rejection is captured by the audit middleware before it leaves. We walk them from the edge inward.

                 https://bridge.nepveu.name
                            │
              ┌─────────────▼─────────────┐
              │    Cloudflare Access      │   service-token gate (90d)
              └─────────────┬─────────────┘
                            │
              ┌─────────────▼─────────────┐
              │  cloudflared tunnel       │   token-based, no local cert.pem
              └─────────────┬─────────────┘
                            ▼
   ┌────────────────────────────────────────────────────┐
   │         Sanctum Gateway (FastAPI, :8443)           │
   ├────────────────────────────────────────────────────┤
   │  Middleware stack (top → bottom):                  │
   │    AuditMiddleware                                 │
   │    RateLimitMiddleware (per CFid)                  │
   │    CfAccessJwtMiddleware (JWKS)                    │
   │    HMACAuthMiddleware (size + sig)                 │
   ├────────────────────────────────────────────────────┤
   │  Routes:                                           │
   │    /sharepoint/upload + /folder  ─────────► Graph  │
   │    /m365/search  ─────────────────────────► Graph  │
   │    /tearsheets/render  ──────► python renderer     │
   │    /slack/post  ─────► dormant (no hmac.slack)     │
   │    /_health  /_manifest  /_diagnostic              │
   │    /_metrics  /mcp/                                │
   ├────────────────────────────────────────────────────┤
   │  secrets.yaml (SOPS+age)  audit.jsonl (newsyslog)  │
   └────────────────────────────────────────────────────┘

At the edge

Two layers stand between the public internet and the Mini — neither is our code.

Layer A — Cloudflare Access (edge)

bridge.nepveu.name sits behind a CF Access app whose only policy is non_identity → service_token. Claude’s sandbox carries CF-Access-Client-Id + CF-Access-Client-Secret; without them the request 403s at the edge, never touching the Mini. Token TTL is 90 days; rotation is automatic (see Operations).

Layer B — Cloudflared tunnel (token-managed)

A token-based tunnel forwards bridge.nepveu.name → localhost:8443 on the Mini. Its UUID, account id, and routing live in the CF Zero Trust dashboard, not ~/.cloudflared/config.yml — no local cert.pem, no config to drift — and it shares the tunnel that already terminates health.nepveu.name.

Inside the process

Past the tunnel, the two outer middlewares watch and throttle — they don’t yet ask who you are.

Layer C — Audit middleware (outermost)

Every request leaves a JSONL line at /var/log/sanctum/audit.jsonl, auth rejections included because it sits outside HMAC. Fields: module, action, method, path, status, latency_ms, body_sha256, cf_access_id. No body, no headers logged. WatchedFileHandler reopens the file when newsyslog rotates the inode (every 50 MB or daily, 7 generations gzip).

Layer D — Rate limit (token bucket per CF Access client id)

Default 10 rps with a 50-token burst, scoped per Cf-Access-Client-Id. Headroom for a skill running fan-out, but it cuts off a runaway loop within seconds. Tunable via SANCTUM_RATE_LIMIT_RPS / SANCTUM_RATE_LIMIT_BURST.

Proving identity and integrity

The inner two layers are where a request proves who it is and that nobody altered it in flight — the part Windu loses sleep over.

Layer E — CF Access JWT verification

CF Access signs a JWT for every authenticated request — even service tokens — and forwards it in Cf-Access-Jwt-Assertion. The middleware verifies it against the team’s JWKS at https://<team_domain>/cdn-cgi/access/certs; <team_domain> comes from cloudflare.team_domain in secrets.yaml, never hardcoded, so the URL can’t drift from the Access app it checks. PyJWT caches keys by kid, refetches on rotation, and matches aud against cloudflare.access_aud. This closes the gap where a tunnel misconfig — or a second cloudflared on the same token — could present trusted-looking Cf-Access-Client-Id headers with no real CF Access flow behind them. Unset cloudflare.team_domain / cloudflare.access_aud make the middleware construct as None and short-circuit — handy for tests and runs with no tunnel.

Layer F — HMAC + size cap (innermost)

Every request to a module action carries:

Authorization: SanctumHMAC v1
X-Sanctum-Module: sharepoint
X-Sanctum-Timestamp: 2026-04-29T16:42:01Z
X-Sanctum-Nonce: 01HXYZ…
X-Sanctum-Signature: <hex>

with signature = HMAC-SHA256(module_secret, f"{timestamp}\n{nonce}\n{method}\n{path}\n{sha256(body)}").

Server-side, in source order (auth.py):

0. Content-Length > 250 MiB → 413 before the body is read — the only check outside _verify.
1. Authorization is exactly SanctumHMAC v1 and all five headers present.
2. X-Sanctum-Module matches the module in the path — you can’t sign for one module and POST to another.
3. Timestamp within ±60 s of UTC.
4. Nonce not seen in the last 5 min (3-bucket bloom filter, 64 KB each).
5. The module’s secret resolves; unknown module rejects here.
6. Signature matches under that secret.

The body’s sha256 is computed once and stashed on the ASGI scope, so the audit layer logs it without re-reading.

Per-module scoped secrets

module_secret differs per bridge (hmac.sharepoint, hmac.slack, …), so a compromised SharePoint secret can’t invoke the Slack module. Stored in /opt/sanctum/bridge/secrets.yaml, SOPS-encrypted with the age key at /opt/sanctum/keys/age.key (mode 600, neo-owned); the public key is also in 1Password as a recovery anchor — the same secrets trifecta the rest of the haus runs on.

Threat model

Windu’s question for any gate is blunt: which single failure does each layer survive?

What this protects against

Attack	Layer that catches it
Public-internet probe	A (CF Access)
Replay of captured request	F (timestamp + nonce)
Body tampering	F (sig covers body hash)
Resource exhaustion via huge POST	F (250 MiB cap before read)
Leaked CF token alone	F (still need HMAC secret)
Leaked HMAC secret alone	A (still need CF token)
Leaked SharePoint secret	per-module scope
Tunnel misconfig / header spoof	E (JWT verified via JWKS)
Runaway skill loop	D (rate limit)

What this does NOT protect against

• Mac Mini host compromise (every secret is at rest there; host hardening is a separate, out-of-scope problem).
• Claude itself being prompt-injected into a malicious upload — mitigated at the skill layer with the explicit-list allowlist (work-skills/sharepoint-structure.yaml), the hard-coded @triptyq.vc suffix on m365 reads, and — once Slack is live — per-channel webhook scoping.

Modules

Four modules ship today. You add a fifth by dropping a bridges/<name>/ package the discovery loop imports at boot — no service rewrite.

sharepoint

App-only auth via MSAL client-credentials against the Triptyq Azure AD app SharePoint MCP Server. Scopes: Sites.ReadWrite.All, Files.ReadWrite.All. Token cached in-process, refreshed at 80 % TTL.

The site ID and a specific drive ID both live in secrets.yaml. Triptyq has multi-library sites (Documents and Documents Triptyq on one /sites/<work-site> URL), so the gateway honors the configured drive explicitly rather than calling /sites/{id}/drive blindly.

Allowed write roots come from work-skills/sharepoint-structure.yaml (private work repo), fetched at startup and refreshed hourly. The parser preserves multi-segment roots verbatim (03_Pipeline/02_Deal Flow), and boundary matching uses path == root or path.startswith(root + "/") so 01_Fund AdminEvilLookalike can’t pass off as 01_Fund Admin.

Upload behavior:

• < 4 MiB — single PUT /drives/{drive}/items/{parent}:/<name>:/content
• >= 4 MiB — Graph upload session, body streamed in 10 MiB chunks
• Native SharePoint versioning under if_exists: "version" (default); the response includes the new version number.
• metadata_applied: bool: false means the file landed but the listItem field PATCH was rejected (usually a custom column undefined in the SP library), so skills branch on it without parsing prose.

m365

/m365/search runs a Graph mail $search over a partner mailbox so a partner Mac can run tq scan-mail without holding the SOPS age key locally, reusing the SharePoint app registration’s credentials with Mail.Read granted. Two guards reject before Graph is touched: a hard-coded @triptyq.vc suffix check (deliberately not env-configurable, so a typo’d allowlist edit can’t pivot to an outside address) and a MailboxAllowlist of current partners. The needle is hashed, never logged — partners search the names of confidential deals, so the audit line carries only its sha256.

tearsheets

Wraps triptyq.generator.render_tearsheet so the portal’s Render button produces a .docx byte-identical to the CLI’s. POST /tearsheets/render takes a slug + quarter (regex-validated), reads the matching <slug>_<quarter>.yaml from the CLI checkout, and returns <slug>_tearsheet_<quarter>.docx base64-encoded. No secrets — the data is on disk — so build() returns None only when the checkout or the triptyq.generator import is missing, which keeps canary hosts clean. Being CPU-bound, it runs in a worker thread so the event loop stays answerable.

slack (dormant)

Code-complete but unconfigured: with no hmac.slack in secrets.yaml, build() returns None and the discovery loop skips it. When it lights up, the model is per-channel incoming webhooks — Council ruled these over a forever-valid bot token: the webhook URL is the destination, so a leak can only spam its own channel. The belt-and-suspenders allowlist at work-skills/slack-allowed-channels.yaml isn’t provisioned yet — create it before going live.

Endpoints

The CF Access JWT layer fronts everything except /_health and /_metrics (the only two paths in _NO_JWT_EXACT), so behind the tunnel the “auth” below is really CF JWT plus the inner gate named.

Path	Auth	Notes
/_health	none	Public liveness — ok, version, commit, started_at, modules, allowlist_count. CF Access still gates the public URL.
/_diagnostic	CF JWT + HMAC	Everything in /_health plus rotator status, request count, full allowlist roots, JWT enabled flag.
/_manifest	CF JWT + HMAC	Module + action listing with JSONSchema for every request/response model. Powers work-skills/scripts/sync-bridge-manifest.py.
/_metrics	none; localhost-bound	Prometheus exposition format. No route-level IP guard — it’s private only because the whole server binds 127.0.0.1.
/mcp/	CF JWT + HMAC	FastMCP streamable_http_app. v0.1 has no MCP-side session auth, so this rides the same HMAC as everything else; the previous “skip /mcp” path was a silent bypass.
/<module>/<action>	CF JWT + HMAC	Module-defined: /sharepoint/upload, /sharepoint/folder, /m365/search, /tearsheets/render today.

Operations

Day-to-day lives in the gateway runbook; the shape is here.

Process supervision

A single LaunchDaemon at /Library/LaunchDaemons/name.nepveu.sanctum-bridge.plist runs /opt/sanctum/bridge/.venv/bin/python -m sanctum_bridge as user neo (via UserName/GroupName). KeepAlive=true, RunAtLoad=true, ThrottleInterval=30 so a bad secrets.yaml or code deploy can’t restart-loop it.

Three user agents back it:

• com.sanctum.bridge-rotate — daily 09:00 local. Self-gates: reads the current CF Access token’s expires_at, exits unless it expires within ROTATE_WITHIN_DAYS=7. In-window it mints a new 90-day token, sets the Access policy to accept BOTH old and new during cutover, verifies external _health with the new creds, then narrows to new-only and deletes the old. A verify failure rolls back — new token deleted, policy reset to old-only, alarm logged — and the next daily run retries.
• com.sanctum.bridge-canary — every 6 h. Writes a tiny payload via the public bridge into 01_Fund Admin/_canary/canary-<host>.txt with if_exists=version; SP’s native versioning then gives a monotonically-climbing count per success, and a stuck count means the path broke.
• com.sanctum.bridge-manifest-sync — daily 06:30 local; runs work-skills/scripts/sync-bridge-manifest.py. Idempotent unless the manifest drifted, when it regenerates the helper’s <!-- AUTO --> block.

Status one-liners land at ~/.sanctum/state/bridge-rotate.status and ~/.sanctum/state/bridge-canary.status for the morning briefing.

Logs

• /var/log/sanctum/audit.jsonl — structured per-request log. WatchedFileHandler + newsyslog rotation: 50 MB or daily, 7 generations, gzip.
• /var/log/sanctum/bridge.out.log + bridge.err.log — uvicorn / structlog stdout / stderr from launchd. Not newsyslog-rotated (launchd won’t reopen the inode); they grow a few hundred KB per year at typical traffic — restart the daemon if they ever balloon.

Backup

The restic SOURCES (~/Backups/sanctum-backup.sh) include /opt/sanctum (the encrypted secrets.yaml, the bridge code, the keys directory) and ~/Projects/work-skills (allowlist SoT + the manifest sync script). The age master key is also in 1Password as a Secure Note — losing the SSD plus the 1P entry plus restic is the only recovery floor.

sanctum bridge doctor

An end-to-end probe that touches Keychain, /_health, /_diagnostic, the rotator status file, allowlist count, and CF Access JWT enablement, then prints a Rich table of green/red rows. Run it as the daily heartbeat: green means Keychain-to-SharePoint is wired correctly; the first red row is what to fix.

Repos

• Ogilthorp3/sanctum-gateway — gateway code, secrets.yaml (encrypted), launchd plists, newsyslog conf.
• work-skills (private work repo) — skill helpers, sharepoint-structure.yaml, sync-bridge-manifest.py.
• Ogilthorp3/sanctum-cli — sanctum bridge {health,whoami,manifest,folder,upload,doctor}.
• Ogilthorp3/sanctum-backup-config — restic + canary scripts on manoir.

Resolved decisions

1. Scopes — read AND write. Sites.ReadWrite.All + Files.ReadWrite.All, reusing the existing SharePoint MCP Server app registration rather than a separate one — operator’s call, 2026-04-28.
2. Allowlist SoT — work-skills/sharepoint-structure.yaml. A stale cache falls back to last-known-good; a new root is a skills-repo PR.
3. Versioning — hybrid. if_exists: "version" (default) uses native versioning; if_exists: "rename" for signed final docs where siblings make sense.
4. MCP transport — streamable-http. Single POST per call, now under HMAC; the original “skip /mcp” path was a silent bypass.
5. Slack auth — per-channel incoming webhooks + channel-ID allowlist. Council 2026-04-29: rotation cadence and the prompt-injection model both point here.
6. Bridge canary — 01_Fund Admin/_canary with if_exists=version. Version count = success count.
7. CF Access rotation — local launchd, not remote agent. The remote path has no Keychain or 1P; com.sanctum.bridge-rotate on manoir runs the full two-token cutover.

The daily green

None of this shows up on a normal day. Claude calls the gateway, the file lands in the right folder, and sanctum bridge doctor prints another green row. Windu approved the layers; nobody upstairs thinks about them again. A good gate earns its keep by being forgotten — until the morning it turns something away, and you are glad you built it.
