CLI Reference

This page documents the command-line tools used to manage, monitor, and maintain a Sanctum instance.

---

Gateway Management

The OpenClaw gateway is the core agent runtime. Always use the openclaw CLI to manage it — never use raw launchctl commands for the gateway.

Start the Gateway

openclaw gateway start

Loads the gateway LaunchAgent and starts the agent runtime on the configured port (default 18789).

Stop the Gateway

openclaw gateway stop

Gracefully shuts down the gateway, cleans up state files and port locks, then unloads the LaunchAgent.

Caution

On the VM, use systemd instead:

systemctl --user restart openclaw-gateway.service

Restart Pattern

# Mac
openclaw gateway stop
openclaw gateway start

# VM
systemctl --user restart openclaw-gateway.service

A convenience script is also available:

~/.sanctum/scripts/gateway-restart.sh

---

Agent Commands

Send a Message to an Agent

openclaw agent --agent <agent_name> --message "<message>"

Flag	Description
--agent	Agent identifier: main (Yoda), windu, quigon, cilghal, mundi, or jocasta
--message	The message to deliver to the agent

# Send a message to the main agent (Yoda)
openclaw agent --agent main --message "Run the evening briefing"

# Send a message to the security agent
openclaw agent --agent windu --message "Generate the weekly security report"

Cross-Node Agent Messaging

For sending messages between Mac and VM agents, use the council bridge SSH pattern:

Mac to VM

ssh ubuntu@10.10.10.10 \
  '/home/ubuntu/.npm-global/bin/openclaw agent --agent main --message "Hello from Jocasta"'

VM to Mac

ssh bert@10.10.10.1 \
  'PATH=/Users/bert/.local/share/fnm/node-versions/v22.22.0/installation/bin:/opt/homebrew/bin:$PATH \
   openclaw agent --agent main --message "Hello from Yoda"'

Note

The VM-to-Mac path requires a PATH prefix because fnm-managed Node.js is not in the default SSH PATH.

---

launchctl Patterns

macOS uses launchctl to manage LaunchAgents and LaunchDaemons. Sanctum uses the modern bootstrap/bootout subcommands.

Load a LaunchAgent

launchctl bootstrap gui/$(id -u) ~/Library/LaunchAgents/<label>.plist

# Example: load the watchdog
launchctl bootstrap gui/$(id -u) ~/Library/LaunchAgents/com.sanctum.watchdog.plist

Unload a LaunchAgent

launchctl bootout gui/$(id -u) ~/Library/LaunchAgents/<label>.plist

# Example: unload the watchdog
launchctl bootout gui/$(id -u) ~/Library/LaunchAgents/com.sanctum.watchdog.plist

Check Agent Status

launchctl print gui/$(id -u)/<label>

# Example: check if the council MLX server is running
launchctl print gui/$(id -u)/com.sanctum.council-mlx

Load a LaunchDaemon

LaunchDaemons require sudo and use the system domain:

sudo launchctl bootstrap system /Library/LaunchDaemons/<label>.plist
sudo launchctl bootout system /Library/LaunchDaemons/<label>.plist

---

generate-plists.sh

Renders LaunchAgent plist files from templates using values from instance.yaml and the macOS Keychain.

~/.sanctum/generate-plists.sh [--dry-run]

Flag	Description
--dry-run	Show what would be generated without writing any files

What It Does

1. Reads templates from ~/.sanctum/templates/launchagents/
2. Checks each template’s corresponding service enabled flag in instance.yaml
3. Skips disabled services
4. Expands {{PLACEHOLDER}} tokens with config values
5. Retrieves secrets from the macOS Keychain using the configured keychain_account
6. Writes rendered plists to ~/Library/LaunchAgents/ (or /Library/LaunchDaemons/)

# Preview changes
~/.sanctum/generate-plists.sh --dry-run

# Generate and install
~/.sanctum/generate-plists.sh

---

run-all.sh (Test Suite)

Runs the full Sanctum test suite to verify all services, connections, and configurations.

~/.sanctum/run-all.sh

The test suite checks:

• All enabled LaunchAgents are loaded and running
• Gateway is responsive on the configured port
• VM is reachable via SSH
• Bridge interface has the correct IP
• All enabled services respond on their configured ports
• Firewalla bridge can authenticate
• Home Assistant is accessible
• Cloudflare tunnel is connected
• Tailscale is connected and peers are reachable
• Node connectivity (LAN and Tailscale)

Output uses color-coded pass/fail indicators. A summary count is printed at the end.

[PASS] Gateway responding on port 18789
[PASS] VM reachable at 10.10.10.10
[PASS] Home Assistant at port 8123
[FAIL] Kiwix server not responding on port 8888
---
Results: 15/16 passed

---

watchdog.sh

The watchdog script runs every 600 seconds via the com.sanctum.watchdog LaunchAgent. It monitors all enabled services and attempts auto-healing via service-doctor.

~/.sanctum/watchdog.sh

Behavior

1. Iterates through all services with enabled: true in instance.yaml
2. Checks each service’s health (port check, process check, or custom probe)
3. If a service is unhealthy, invokes service-doctor to attempt recovery
4. Logs all results to ~/.sanctum/logs/watchdog.log
5. Sends a notification via sanctum_notify if any service required healing

Manual Run

Run the watchdog manually to check current health:

~/.sanctum/watchdog.sh

---

sanctum-backup.sh

Creates a backup of the Sanctum configuration and critical state files.

~/.sanctum/sanctum-backup.sh [--destination <path>]

Flag	Description
--destination	Override the default backup directory (from paths.backups in config)

What Gets Backed Up

Item	Description
instance.yaml	Central configuration
templates/	LaunchAgent plist templates
lib/	Shell and Python libraries
Agent configs	OpenClaw/DenchClaw configuration
HA config	Home Assistant configuration.yaml and automations
VM state	Key VM configuration files (via SSH)
Keychain exports	Metadata only (not the actual secrets)

# Default backup to configured path
~/.sanctum/sanctum-backup.sh

# Backup to a specific location
~/.sanctum/sanctum-backup.sh --destination /Volumes/External/sanctum-backup

Backups are timestamped and stored as compressed archives:

~/.sanctum/backups/sanctum-backup-2026-03-19T120000.tar.gz

---

sanctum-restore.sh

Restore a Sanctum instance from a backup archive.

~/.sanctum/sanctum-restore.sh <backup_file>

Argument	Description
backup_file	Path to a .tar.gz backup archive

~/.sanctum/sanctum-restore.sh ~/.sanctum/backups/sanctum-backup-2026-03-19T120000.tar.gz

Restore Process

1. Validates the backup archive integrity
2. Extracts to a temporary directory for review
3. Shows a diff of what would change
4. Prompts for confirmation before overwriting
5. Restores configuration files
6. Re-runs generate-plists.sh to regenerate LaunchAgents
7. Optionally restarts affected services

Caution

Restore does not automatically reload LaunchAgents. After a restore, you should either reboot or manually reload affected services via launchctl.

---

Quick Reference

Command	Purpose
openclaw gateway start	Start the Mac gateway
openclaw gateway stop	Stop the Mac gateway
openclaw agent --agent main --message "..."	Send a message to an agent
~/.sanctum/generate-plists.sh	Regenerate all LaunchAgent plists
~/.sanctum/generate-plists.sh --dry-run	Preview plist generation
~/.sanctum/run-all.sh	Run the full test suite
~/.sanctum/watchdog.sh	Run the health watchdog manually
~/.sanctum/sanctum-backup.sh	Create a configuration backup
~/.sanctum/sanctum-restore.sh <file>	Restore from a backup
launchctl bootstrap gui/$(id -u) <plist>	Load a LaunchAgent
launchctl bootout gui/$(id -u) <plist>	Unload a LaunchAgent
launchctl print gui/$(id -u)/<label>	Check agent status
systemctl --user restart openclaw-gateway	Restart VM gateway
