Home Assistant Integration

Home Assistant is Sanctum’s home automation hub. It runs as a Docker container on the Mac Mini with bridge networking, integrating Sonos speakers, HomeKit devices, and providing remote access through a Cloudflare tunnel.

Architecture

┌──────────────────────────────────────────────┐
│ Mac Mini                                      │
│                                               │
│  ┌─────────────────────────────────────────┐  │
│  │ Docker (bridge network)                 │  │
│  │                                         │  │
│  │  ┌─────────────────────────────────┐    │  │
│  │  │ Home Assistant Container        │    │  │
│  │  │  Port 8123 → Web UI            │    │  │
│  │  │  Port 21063 → HomeKit Bridge   │    │  │
│  │  │  SSH agent → VM access         │    │  │
│  │  └─────────────────────────────────┘    │  │
│  └─────────────────────────────────────────┘  │
│                                               │
│  Cloudflare Tunnel → ha.nepveu.name           │
└──────────────────────────────────────────────┘

HA was migrated from the VM to Mac Docker because SLIRP networking on the VM proved unreliable for the number of integrations and real-time device communication required.

Docker Configuration

The container uses bridge networking rather than --network=host because host networking is not supported on macOS Docker.

Key Settings

Setting	Value
Image	ghcr.io/home-assistant/home-assistant:stable
Network mode	bridge
Web UI port	8123
HomeKit port	21063
Config directory	~/.openclaw/homeassistant/
Restart policy	unless-stopped

Compose File

The compose.yaml at ~/.openclaw/homeassistant/ defines the container with these essential directives:

• Port mappings: 8123:8123 (web), 21063:21063 (HomeKit)
• Volume mount: Local config directory into /config
• Extra hosts: host.docker.internal:host-gateway for reaching Mac services from inside the container
• SSH agent socket: /run/host-services/ssh-auth.sock mounted for agent forwarding to the VM

Docker Desktop is configured with auto-start enabled, ensuring HA comes up after a reboot without manual intervention.

Sonos Integration

Sanctum manages 10 Sonos speakers. Because the HA container runs in bridge networking mode, mDNS/SSDP discovery does not work. All speakers must be configured as known hosts in configuration.yaml.

sonos:
  media_player:
    hosts:
      - 192.168.1.101
      - 192.168.1.102
      # ... all 10 speaker IPs

Caution

If a Sonos speaker changes IP address (e.g., after a router reboot), it will become unreachable until the configuration.yaml is updated with the new IP. Use Firewalla DHCP reservations to keep speaker IPs stable.

Text-to-Speech on Sonos

The XTTS-v2 TTS server runs on the Mac (port 8020, using MPS GPU acceleration). To play speech on Sonos speakers, use the media_player.play_media service with a media-source://tts/ URI and the announce: true flag.

Note

The tts.speak service does not dispatch audio to Sonos. Always use media_player.play_media with a TTS media source URI for Sonos announcements.

SSH Agent Forwarding

The HA container needs SSH access to the VM for certain automations and scripts. This is accomplished by mounting the Mac’s SSH agent socket into the container.

The SSH agent socket at /run/host-services/ssh-auth.sock is mapped as a volume in the compose file. Scripts inside the container can then SSH to ubuntu@10.10.10.10 using the Mac’s loaded SSH keys without storing any private keys in the container.

SSH wrapper scripts live at ~/.openclaw/ha-scripts/ and exec SSH directly to the VM with agent forwarding enabled.

Network Configuration

The configuration.yaml includes network-specific settings for the bridge networking environment:

homeassistant:
  internal_url: "http://192.168.1.10:8123"
  external_url: "https://ha.nepveu.name"

http:
  use_x_forwarded_for: true
  trusted_proxies:
    - 172.16.0.0/12
    - 192.168.64.0/20

The trusted proxies cover Docker’s internal bridge subnets, allowing HA to correctly identify client IPs when accessed through the Cloudflare tunnel or Docker’s bridge network.

Remote Access

External access to HA is provided through a Cloudflare tunnel running as a LaunchAgent on the Mac.

Component	Details
Tunnel name	manoir-nepveu
LaunchAgent	com.cloudflare.tunnel
External URL	https://ha.nepveu.name
Route	ha.nepveu.name to localhost:8123
DNS	Cloudflare managed (nepveu.name)

The tunnel provides HTTPS termination and Cloudflare Zero Trust access controls without exposing any ports to the public internet.

HomeKit Bridge

The HomeKit bridge runs on port 21063, allowing Apple Home app control of HA-managed devices.

Setting	Value
Port	21063
Pairing code	840-97-709

HomeKit entities are configured within HA’s integration settings. The bridge exposes selected devices to Apple Home while keeping the full HA device list available through the web UI.

Management

Starting and Stopping

# Start HA
cd ~/.openclaw/homeassistant && docker compose up -d

# Stop HA
cd ~/.openclaw/homeassistant && docker compose down

# View logs
docker logs -f homeassistant

# Restart
cd ~/.openclaw/homeassistant && docker compose restart

Rollback

If the Mac Docker instance has issues, a rollback path exists to the VM:

1. Stop the Mac container: docker compose down
2. SSH to the VM: ssh openclaw
3. Start the VM instance: ~/.openclaw/ha-docker.sh recreate

Note

The VM still has a preserved HA configuration at ~/.openclaw/homeassistant/. The VM instance is stopped but not removed, making rollback straightforward.
