Command Center Dashboard

The command center dashboard is the primary interface for monitoring and managing a Sanctum instance. It provides real-time visibility into service health, VM status, Docker containers, network peers, and AI model availability.

Architecture

The dashboard runs a Vite + React frontend served by an Express backend on port 3001. A reverse proxy LaunchDaemon forwards port 80 to 3001, enabling clean browser access via the instance hostname.

Browser → http://manoir-nepveu (port 80)
       → socat LaunchDaemon (port 80 → 3001)
       → Express backend (port 3001)
       → Vite/React frontend

Dashboard Panels

The dashboard renders conditionally based on services enabled in instance.yaml. Each panel polls its data source independently.

Service Health

Displays the status of every LaunchAgent and systemd unit tracked by the health subsystem. Services are grouped by category (core, AI, network, monitoring) with color-coded indicators:

Green — running, passed last health check
Yellow — running, degraded (e.g., high memory usage)
Red — stopped or failing health checks
Grey — disabled in configuration

VM Status

Shows the Ubuntu VM state as reported by UTM, including CPU core count, memory allocation, disk usage, and network connectivity on the bridge100 interface.

Docker Containers

Lists all Docker containers with their image, status, port mappings, and resource consumption. The Home Assistant container is highlighted when present.

LaunchAgents

Enumerates all Sanctum-managed LaunchAgents with their loaded/running state, PID, last exit status, and any recent restart events.

Tailscale Peers

Renders the Tailscale network topology showing all connected devices, their IP addresses, online status, and last seen timestamps.

LM Studio Models

Queries LM Studio on port 1234 for loaded and available models, displaying model name, parameter count, quantization level, and VRAM usage.

Alerts

Shows active and recent alerts from the watchdog system with severity, source, message, and timestamp. Alerts can be acknowledged directly from the panel.

API Endpoints

The Express backend exposes several endpoints consumed by the frontend and available for external tooling.

GET /api/health/status

Returns the current health status of all monitored services.

{
  "status": "degraded",
  "services": {
    "openclaw-gateway": { "status": "running", "pid": 1234, "uptime": "4d 12h" },
    "home-assistant": { "status": "running", "pid": 5678, "uptime": "2d 8h" },
    "utm-vm": { "status": "running", "cpu": "8 cores", "memory": "12GB" }
  },
  "timestamp": "2026-03-19T14:30:00Z"
}

GET /api/config

Serves the instance configuration from instance.yaml with secrets excluded. Used by the frontend to determine which panels to render and how to label the instance.

GET /api/alerts

Returns active alerts with optional query parameters for filtering by severity and time range.

Parameter	Type	Description
`severity`	string	Filter: `critical`, `warning`, `info`
`since`	string	ISO 8601 timestamp for lower bound
`limit`	number	Maximum results (default: 50)

GET /api/health/tests

Runs the full health test suite on demand and returns results. This is the same suite executed by the watchdog on its periodic schedule.

Proxied Services

The dashboard backend proxies requests to services that are not directly accessible from the browser.

Firewalla

Firewalla API calls are proxied through the Express backend, which handles the cloud authentication handshake and local P2P connection on port 8833. The frontend never communicates with Firewalla directly.

Home Assistant

HA API requests are forwarded to localhost:8123 through the backend, which injects long-lived access tokens stored in the Keychain. This avoids exposing HA tokens to the browser.

Configuration

Dashboard behavior is driven by instance.yaml:

services:
  command-center:
    enabled: true
    port: 3001
    bind: lan

The bind: lan directive restricts the Express server to the LAN interface. The socat LaunchDaemon handles port 80 forwarding separately.

LaunchAgent

The dashboard runs as a persistent LaunchAgent:

Property	Value
Label	`com.manoir.command-center`
RunAtLoad	true
KeepAlive	false
Port	3001
